Главная » Душевая панель с рычажным смесителем PRESTOTEM2 SINGLE CONTROL
88816.jpg Zoom
88816.jpg mj.pdf

Душевая панель с рычажным смесителем PRESTOTEM2 SINGLE CONTROL

Артикул: P88816
Бренд:
Единица: шт
Время доставки: 14-21 день

Попробуй промокод PEGU-KEVAD! Выбери товар по полной цене, добавь в корзину, и введи код купона при покупке! Время работы промокода ограничено!

ESTO järelmaks kuumaks al. 92,36 €
Цена:
1073,60 €
Kuumakse alates: 92,36 €
Кол-во: - +

> Working pressure :

1 to 5 bar

> Flow :

10 l/min with integrated flow limiter
Fixed shower head with anti-limescale spikes

> Hydraulic supply :

G 1/2" (15x21), top or rear water inlet. For rear water inlet, we recommend to add the adaptation kit under the reference 91026 Single control mixer tap with ceramic disks

> Material :

Anodised aluminium extruded section (2.5mm thickness) Aluminium removable valve plate, peinted RAL 7005 colour High resistance RAL 7005 coloured ABS covers

> Functioning:

Wide opening panel without the need to dismantle from the wall and shower taps on a removable valve plate

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Adjustable tamper-proof temperature limiter to prevent scalding

> Delivered with :

1/2" hoses with revolving nuts
MM 1/2" (15x21) straight stop valves and 250 micron filters Fastening screws and instruction manual

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12165 Chrome-plated surface treatment in accordance with EN 12540 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
