General description

•   Wall-mounted steel white grab bar with three support points, made of diameter 32 mm tube, designed for ensuring the safety in the wash basin area, preventing falls throughout this place.

•   With white Polypropylene snap flange covers to conceal the screws, designed to snap on easily for a snug fit. They protect the flange surfaces from damage, dust, moisture and foreign particles and help to achieve a beautiful and sleek look, at the same time.

•   Suitable for domestic and commercial places to design barrier-free accessibility, enabling access and assisting mobility of people with disabilities, or special needs, helping make their lives easier.

•   Optionally, these bars can be electrically isolated by installing the electrical isolation Kit code KA0010.

•   Fixing screws for brick walls included.

  Components and materials

•   BFD600: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, white finish.

•   BFI600: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, white finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along

  the bends.

•   CONCEALED MOUNTING FLANGE: three units made of steel, 3 mm thick. Incorporates three Ø 6.5 mm screws holes for wall

  mounting.

•   SNAP FLANGE COVER: three units made of Polypropylene, 1.5 mm thick and Ø 85 mm. Each cover snaps over mounting flange to

General description

L454 x L869 mm

•   Grab bar, 90o angle to the right (BAD090C & BAD090CS) or to the left (BAI090C & BAI090CS) with snap flange cover, made of stainless steel AISI 304, for showers, baths and changing rooms.

•   These grab bars are very useful and highly recommended to achieve barrier-free accessibility both residential and public spaces.

•   Concealed screw mounting flanges.

•   Highest durability and rusting resistance.

•   Mounting hardware for brick wall is included for easy installation.

  Components and materials

•   BAD090C & BAI090C: AISI 304 stainless steel, bright finish.

•   BAD090CS & BAI090CS: AISI 304 stainless steel, satin finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along

  the bends.

•   CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes

  for wall mounting.

•   SNAP FLANGE COVER: three units made of stainless steel AISI 304, 1.5 mm thick and Ø 82 mm. Each cover snaps over mounting

flange to conceal mounting screws.
