Аварийный душ – очень важный элемент для безопасного рабочего места!

Broen-Lab также доступен в Эстонии





Kataloog Hädaabidušid BROEN-LAB

Сортировать по:
Показать как: список / сетку







SOS dušš, seinale kinnituv 1/2"

Артикул: BR-17082009 ,   Время доставки: 7 дней
432,00 € (10%)
480,00 €

SOS dušš, seinale kinnituv 1/2"

Артикул: BR-17087009 ,   Время доставки: 7 дней
615,60 € (10%)
684,00 €
LAB смеситель с рычагом H-300mm, S-200mm

S P E C I F I CATIONS
Handle: Metal, BROEN POLYCOAT powder coated
Spout: Swivel action
Hose nozzle: Aerator
Cartridge: Ceramic (temperature and flow regulation type)
Opening/closing function: 25°, mixing function: ±45°
Temperature range: 0°C - 90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 2.4 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- removable hose nozzle
MOUNTING INFORMATION
Артикул: B-25350391035-52B(15304459) ,   Время доставки: 2-3 недели
499,20 €
S P E C I F I CATIONS
The fitting is delivered with an integrated BALLOFIX® ball valve.
Handle: Metal, BROEN POLYCOAT powder coated
with media indication according to EN13792
Spout: Full swivel action
Hose nozzle: Removable metal
Headwork: Ceramic
Opening/closing function: 180° (wrist action lever: 90°)
Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 3 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
Solder: DIN L-Ag55:Sn
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- aerator
- fixed hose nozzle
- integrated non-return valve
- alternative hose inlet connection / without a hose
- other inlet options (type, length)
- national approvals
Артикул: B-25360011039-52B ,   Время доставки: 3-4 дня
264,60 € (10%)
294,00 €
S P E C I F I CATIONS
The fitting is delivered with an integrated BALLOFIX® ball valve.
Handle: Metal, BROEN POLYCOAT powder coated
with media indication according to EN13792
Spout: Full swivel action
Hose nozzle: Removable metal
Headwork: Ceramic
Opening/closing function: 180° (wrist action lever: 90°)
Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 3 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
Solder: DIN L-Ag55:Sn
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- aerator
- fixed hose nozzle
- integrated non-return valve
- alternative hose inlet connection / without a hose
- other inlet options (type, length)
- national approvals
Артикул: B25360021039-52B ,   Время доставки: 3-4 дня
297,00 € (10%)
330,00 €
S P E C I F I CATIONS
The fitting is delivered with an integrated BALLOFIX® ball valve.
Handle: Metal, BROEN POLYCOAT powder coated
with media indication according to EN13792
Spout: Full swivel action
Hose nozzle: Removable metal
Headwork: Ceramic
Opening/closing function: 180° (wrist action lever: 90°)
Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 3 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
Solder: DIN L-Ag55:Sn
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- aerator
- fixed hose nozzle
- integrated non-return valve
- alternative hose inlet connection / without a hose
- other inlet options (type, length)
- national approvals
Артикул: B-25360131039-52B ,   Время доставки: 3-4 дня
306,00 €

Sees 290x290 (vajab põhjaklappi 97B0073)

S P E C I F I CATIONS
Temperature range: 0-800C
Standard colour: black
Net weight: 1.6 kg
Dimensions: external 345 x 345 x 235mm (tolerance ± 1mm)
Injection moulded from polypropylene copolymer resin, with
a self-draining base. This square PP sink blends well into any
laboratory workbench. Extremely durable.
Артикул: B-97B0350 ,   Время доставки: 7-14 дней
103,50 € (10%)
115,00 €

Sees 492x282 (vajab põhjaklappi 97B0073)

SPECIFICATIONS
Temperature range: 0-80°C
Standard colour: black
Net weight: 2.2 kg
Dimensions: external 552 x 400 x 237mm (tolerance ± 1mm)
The rectangular sink with its self draining base are injection moulded from polypropylene copolymer resin. Designed for mounting on top or underside of work benches.
Артикул: B-97B0552 ,   Время доставки: 2-3 nädalad
117,00 € (10%)
130,00 €
Артикул: B-6014 ,   Время доставки: 3-5 дней
65,45 € (15%)
77,00 €
Артикул: B-6001 ,   Время доставки: 3-5 дней
63,75 € (15%)
75,00 €
Артикул: B-6000 ,   Время доставки: 3-5 дней
63,75 € (15%)
75,00 €
SPECIFICATIONS
Temperature range: 0-80°C
Standard colour: black
Net weight: 0.2 kg
Dimensions: Ø73, 1½” BSP (tolerance ± 1mm)
Including adjustable screw on nutø
Артикул: B-97B0073 ,   Время доставки: 2-3 nädalad
16,20 € (10%)
18,00 €
SPECIFICATIONS
Temperature range: 0-80°C
Standard colour: black (other colours available on request )
Net weight: 0.5 kg
Dimensions: IN: 1½” BSP
OUT: 40mm (metric)
Height adjustable: telescopic bottle trap
Injection moulded from polypropylene copolymer resin, this anti-siphon bottle trap come with inlet of 1½” BSP, with black bowl.
PP BOTTLE TRAP
PRODUCT NUMBER 97B0040
PRODUCT NUMBER 97B0023
SPECIFICATIONS
Temperature range: 0-80°C
Standard colour: black (other colours available on request )
Net weight: 0.5 kg
Dimensions: IN: 1½” BSP
OUT: 40mm (metric)
Injection moulded
Артикул: B-97B0040 (97B0080) ,   Время доставки: 2-3 nädalad
48,00 €
S P E C I F I CATIONS
The fitting is delivered with an integrated BALLOFIX® ball valve.
Handle: Metal, BROEN POLYCOAT powder coated
with media indication according to EN13792
Spout: Full swivel action
Hose nozzle: Removable metal
Headwork: Ceramic
Opening/closing function: 180° (wrist action lever: 90°)
Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 1.4 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- aerator
- fixed hose nozzle
- integrated non-return valve
- fixed spout
- alternative hose inlet connection / without a hose
- other inlet options (type, length)
- national approvals
- WPH (Water Potable Hot)
- WNH (Water Non-Potable Hot)
Артикул: B-25340011001-52B ,   Время доставки: 3-7 дней
193,80 € (5%)
204,00 €
S P E C I F I CATIONS
The fitting is delivered with an integrated BALLOFIX® ball valve.
Handle: Metal, BROEN POLYCOAT powder coated
with media indication according to EN13792
Spout: Full swivel action
Hose nozzle: Removable metal
Headwork: Ceramic
Opening/closing function: 180° (wrist action lever: 90°)
Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 1.4 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- aerator
- fixed hose nozzle
- integrated non-return valve
- fixed spout
- alternative hose inlet connection / without a hose
- other inlet options (type, length)
- national approvals
- WPH (Water Potable Hot)
- WNH (Water Non-Potable Hot)
Артикул: B-25340021001-52B ,   Время доставки: 3-7 дней
199,50 € (5%)
210,00 €
S P E C I F I CATIONS
The fitting is delivered with an integrated BALLOFIX® ball valve.
Handle: Metal, BROEN POLYCOAT powder coated
with media indication according to EN13792
Spout: Full swivel action
Hose nozzle: Removable metal
Headwork: Ceramic
Opening/closing function: 180° (wrist action lever: 90°)
Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 1.4 kg
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: POM, PTFE, SPX (hose)
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96%
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- aerator
- fixed hose nozzle
- integrated non-return valve
- fixed spout
- alternative hose inlet connection / without a hose
- other inlet options (type, length)
- national approvals
- WPH (Water Potable Hot)
- WNH (Water Non-Potable Hot)
Артикул: B-25340161001-52B ,   Время доставки: 3-7 дней
216,00 €
Broen-Lab Greenline nood-oogdouchecombinatie, aansluitmaat 1.1/4", 1 sproeikop, vloer, binnendraad, bediening nooddouche trekstang (pullhandle), elektronisch 24V, incl. ogendouche, met opvangbak, oogdouche met opvangbak


Артикул: B-H7410021000321 ,   Время доставки: 3-4 недели
7476,00 €
Ögondusch för bänk med skål

Ögon/ansiktsdusch med skål och bänkfäste. Alla delar är ytbehandlade med BROEN-LABs POLYCOAT som inte bara gör att ögon- & ansiktsduschen syns väldigt bra, den står även emot de flesta kemikalier, UV blekning och värme. Utrustad med FLOWFIX som gör spolbilden stadig i varierande vattentryck.

• Min. arbetstryck: 1,5 bar
• Fälls in i bänk
• POLYCOAT står emot de flesta kemikalier
• Uppsamlingsskål i rostfritt stål med POLYCOAT
• FLOWFIX: 26 l/min
• 2-sidig efterlysande skylt, dekal & testkort
• Vikt: ca. 3,5 kg
• Anslutning: inv. DN15
• Avloppsanslutning: inv. DN32

Artikelnummer: 17 934 009

Артикул: B-17934009 ,   Время доставки: 3-4 недели
1038,00 €




Skyddsblandare för ögondusch

Termostatisk skyddsblandare, med väggfäste, för ögondusch.
Kompenserar för temperatursvängningar i systemet.

•Stänger av varmvattnet vid ett kallvattenbortfall
•Släpper igenom tillgängligt kallvatten vid bortfall av varmvatten
•Material: Mässing
•Ytbehandling: BROEN POLYCOAT
•Max kapacitet: Ca 30 lit/min
•Vikt: Ca. 1,5 kg
•Anslutning: Utv. DN15

Artikelnummer: 17 140 039


•Tillbehör: Väggfäste 2610046 till skyddsblandare
komplett med vinkelballofix. Utv. anslutning DN15

Артикул: B-17140009 ,   Время доставки: 3-4 недели
717,25 € (5%)
755,00 €


Nöddusch med takfläns för dolda rör

Takmonterad kroppsdusch inkl. takfläns. Alla delar är ytbehandlade med BROEN-LABs POLYCOAT som inte bara gör att förstahjälpen utrustningen syns väldigt bra, den står  även emot de flesta kemikalier, UV blekning och värme.

• Kroppsdusch med effektiv spolbild
• POLYCOAT står emot de flesta kemikalier
• 3-sidig efterlysande skylt monterad på dragstång, dekal & testkort
• Vikt: ca. 2kg
• Flöde 60l/min., vid 1,5 bar (Rör dimensioner anpassas för detta flöde)
• Anslutning: inv. DN15
Artikelnummer: 17 080 009
RSK nummer: 755 96 54

Артикул: B-17080009 ,   Время доставки: 3-4 недели
420,00 €
BROEN-LAB fully recirculating fittings ensure constant fresh
water with no dead legs even when the point-of-use valve is in closed position.
The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.
SPECIFICATIONS
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable plastic
Headwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°
Temperature range: 0-65°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 1.8 kg
MATERIALS WITH MEDIA CONTACT
Diaphragm: PTFE
Plastics: PP, PP-n, PVDF
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- also available in ABS (1, 11/4 , 11/2)
Артикул: B-25330431003 ,   Время доставки: 14-21 день
486,00 €
BROEN-LAB fully recirculating fittings ensure constant fresh
water with no dead legs even when the point-of-use valve is in closed position.
The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.
SPECIFICATIONS
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable plastic
Headwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°
Temperature range: 0-65°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 1.8 kg
MATERIALS WITH MEDIA CONTACT
Diaphragm: PTFE
Plastics: PP, PP-n, PVDF
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item
numbers below.
Other options:
- also available in ABS (1, 11/4 , 11/2)
Артикул: B-25330431036 ,   Время доставки: 14-21 день
486,00 €

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330011003 ,   Время доставки: 14-21 день
300,00 €

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330011036 ,   Время доставки: 14-21 день
300,00 €

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330021003 ,   Время доставки: 14-21 день
306,00 €

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330021036 ,   Время доставки: 14-21 день
306,00 €

Portable eyes and body shower with one spray head



Characteristics

  • suitable for medical facilities and industry
  • used as first aid if eyes impacted by accidents caused by fire, chemical or other dangerous substances in places where there is no access to water
  • portable eyewash and body shower with one spray head
  • stainless steel cylinder cover

Technical information

Capacity: 15 l
Min. operating temperature: +1°C
Rate of flow: 8 l/min. (inf. data)
Артикул: B-H7170011000303 ,   Время доставки: 3-4 недели
2280,00 €

SOS dušš, seinale kinnituv 1/2"

Артикул: BR-17582009 ,   Время доставки: 7-14 дней
437,40 € (10%)
486,00 €
Артикул: BR-17528009 ,   Время доставки: 7-14 дней
933,00 €
Nöd-ögondusch med väggfäste

Kombinerad kropps- & ögon/ansiktsdusch  med skål för väggmontage.
Utrustad med självdränerande duschsil och ögondusch för minskad bakterietillväxt. Den röda POLYCOAT-lackerade rörstommen gör inte bra att första hjälpenutrustningen syns väldigt bra, den står även emot de flesta kemikalier, UV- blekning och värme.

• Kroppsdusch med effektiv spolbild, självdränerande duschsil
• Självdränerande ögon/ansiktsdusch med FLOWFIX 26 lit/min
• POLYCOAT-lackerad rörstomme
• Uppsamlingsskål i rostfritt stål med POLYCOAT
• 3-sidig efterlysande skylt monterad på dragstång, dekal & testkort
• Vikt: ca. 10 kg
• Anslutning: inv. DN20 i toppen eller botten
• Avloppsanslutning: inv. 1 1/4”


Artikelnummer: 17 452 009
RSK nr: 755 9678

Артикул: B-17552009 ,   Время доставки: 2-3 недели
1722,00 €
