LAB Смеситель, Кран

Для ценовых запросов на проект, или по поводу доставки в страны ЕС, просим присылать информацию на e-mail: info@pegu.ee

Консультация по телефону 09.00-19.00, +372 515 0681

Soodus

LAB смеситель , F-150mm, WPH/WPC (15281009)

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 3 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

Solder: DIN L-Ag55:Sn

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

Артикул: B-25360011039-52B , Время доставки: 3-4 дня

232,20 € (10%)
258,00 €

Добавить к желаемым

Сравнить

Soodus

LAB смеситель , F-200mm, WPH/WPC (15281009)

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 3 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

Solder: DIN L-Ag55:Sn

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

Артикул: B25360021039-52B , Время доставки: 3-4 дня

245,10 € (5%)
258,00 €

Добавить к желаемым

Сравнить

LAB смеситель , F-250mm, WPH/WPC (152823009)

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 3 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

Solder: DIN L-Ag55:Sn

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

Артикул: B-25360131039-52B , Время доставки: 3-4 дня

258,00 €

Добавить к желаемым

Сравнить

LAB смеситель с рычагом H-300mm, S-200mm

S P E C I F I CATIONS

Handle: Metal, BROEN POLYCOAT powder coated

Spout: Swivel action

Hose nozzle: Aerator

Cartridge: Ceramic (temperature and flow regulation type)

Opening/closing function: 25°, mixing function: ±45°

Temperature range: 0°C - 90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 2.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- removable hose nozzle

MOUNTING INFORMATION

Артикул: B-25350391035-52B(15304459) , Время доставки: 3-4 дня

384,00 €

Добавить к желаемым

Сравнить

Кран для деионизированной воды S150mm, настенный WDC

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330011036 , Время доставки: 14-21 день

231,00 €

Добавить к желаемым

Сравнить

Кран для деионизированной воды S150mm, с рециркуляцией d25mm WDC

BROEN-LAB fully recirculating fittings ensure constant fresh

water with no dead legs even when the point-of-use valve is in closed position.

The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.

SPECIFICATIONS

Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792

Hose nozzle: Removable plastic

Headwork: Diaphragm type

Opening/closing function: 1 1/2 x 360°

Temperature range: 0-65°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.8 kg

MATERIALS WITH MEDIA CONTACT

Diaphragm: PTFE

Plastics: PP, PP-n, PVDF

Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- also available in ABS (1, 11/4 , 11/2)

Артикул: B-25330431036 , Время доставки: 14-21 день

373,00 €

Добавить к желаемым

Сравнить

Кран для деионизированной воды S200mm, настенный WDC

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330021036 , Время доставки: 14-21 день

241,00 €

Добавить к желаемым

Сравнить

Кран для дистиллированной воды S150mm, настенный WDI

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330011003 , Время доставки: 14-21 день

231,00 €

Добавить к желаемым

Сравнить

Кран для дистиллированной воды S150mm, с рециркуляцией d25mm WDI

BROEN-LAB fully recirculating fittings ensure constant fresh

water with no dead legs even when the point-of-use valve is in closed position.

The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.

SPECIFICATIONS

Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792

Hose nozzle: Removable plastic

Headwork: Diaphragm type

Opening/closing function: 1 1/2 x 360°

Temperature range: 0-65°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.8 kg

MATERIALS WITH MEDIA CONTACT

Diaphragm: PTFE

Plastics: PP, PP-n, PVDF

Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- also available in ABS (1, 11/4 , 11/2)

Артикул: B-25330431003 , Время доставки: 14-21 день

373,00 €

Добавить к желаемым

Сравнить

Кран для дистиллированной воды S200mm, настенный WDI

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Артикул: B-25330021003 , Время доставки: 14-21 день

241,00 €

Добавить к желаемым

Сравнить

Soodus

Кран на холодную , или смешаную воду F-150MM

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Артикул: B-25340011001-52B , Время доставки: 3-7 дней

156,60 € (10%)
174,00 €

Добавить к желаемым

Сравнить

Кран на холодную , или смешаную воду F-200MM

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Артикул: B-25340021001-52B , Время доставки: 3-7 дней

174,00 €

Добавить к желаемым

Сравнить

Кран на холодную , или смешаную воду F-300MM

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Артикул: B-25340161001-52B , Время доставки: 3-7 дней

174,00 €

Добавить к желаемым

Сравнить

Насос вакуумный с обратным клапаном

Boss 19198009 Lab.Armatur DN15

Артикул: B-19198009 , Время доставки: 14-21 день

104,00 €

Добавить к желаемым

Сравнить

Description

Technical features

LAB Смеситель, Кран

информация

дополнительно

мой счет

Контакт
