Душевые поддоны из нержавеющей стали
DESCRIPTION
Recessed shower tray
Ref. 150100
Recessed shower tray, 700 x 700mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm.
One-piece pressed shower tray, seam-free for easy maintenanceand better hygiene.
Rounded internal corners for improved safety in the shower.
Drainage slope.
Supplied with 1 ½" waste.
Non-slip surface.
CE marked. Complies with European standard EN 14527.
Weight: 5.5kg.
TECHNICAL FEATURES
Recessed shower tray
Ref. 150100
| Depth | 60mm |
|---|---|
| Length | 700mm |
| Width | 700mm |
| Thickness | 1.2mm |
| Finish | 304 polished satin stainless steel |
DESCRIPTION
Recessed shower tray
Ref. 150300
Recessed shower tray, 800 x 800mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm.
One-piece pressed shower tray, seam-free for easy maintenanceand better hygiene.
Rounded internal corners for improved safety in the shower.
Drainage slope.
Supplied with 1 ½" waste.
Non-slip surface.
CE marked. Complies with European standard EN 14527.
Weight: 7kg.
TECHNICAL FEATURES
Recessed shower tray
Ref. 150300
| Depth | 60mm |
|---|---|
| Length | 800mm |
| Width | 800mm |
| Thickness | 1.2mm |
| Finish | 304 polished satin stainless steel |
DESCRIPTION
PMR recessed shower tray
Ref. 150500
Recessed shower tray, 800 x 800mm.
Suitable for people with reduced mobility: slimline shower tray.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm
Drainage slope.
Supplied with 1 ½" waste.
Non-slip surface.
CE marked. Complies with European standard EN 14527.
Weight: 8.5kg.
TECHNICAL FEATURES
PMR recessed shower tray
Ref. 150500
| Depth | 30mm |
|---|---|
| Length | 800mm |
| Width | 800mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
DESCRIPTION
PMR recessed shower tray
Ref. 150600
Recessed shower tray, 900 x 900mm.
Suitable for people with reduced mobility: slimline shower tray.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm
Drainage slope.
Supplied with 1 ½" waste.
Non-slip surface.
CE marked. Complies with European standard EN 14527.
Weight: 9.5kg.
TECHNICAL FEATURES
PMR recessed shower tray
Ref. 150600
| Depth | 30mm |
|---|---|
| Length | 900mm |
| Width | 900mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
DESCRIPTION
SECURITHERM Securitouch thermostatic shower mixer
Ref. H9741
SECURITHERM dual control thermostatic shower mixer with:
- Anti-scalding failsafe: hot water shuts off immediately if cold water supply fails (and vice versa).
- Securitouch thermal insulation to prevent burns.
- Scale-resistant thermostatic cartridge for temperature adjustment.
- 1/4-turn ceramic head for flow rate adjustment.
- Temperature control: 25 - 41°C.
- Double temperature limiter: first limiter set at 38°C can be overridden, second limiter set at 41°C.
- Thermal shocks are easy to undertake without removing the control knob or shutting off the cold water supply.
- Flow rate regulated at 9 lpm.
- Chrome-plated brass body and ERGO controls.
- M1/2" shower outlet.
- M3/4" inlets with integrated filters and non-return valves.
Mixer supplied with offset M1/2" M3/4" STOP/PURGE connectors, suitable for hospitals.
TECHNICAL FEATURES
SECURITHERM Securitouch thermostatic shower mixer
Ref. H9741
| Connector | M1/2" |
|---|---|
| Technology | SECURITHERM dual control thermostatic, Securitouch |
| Depth | 95mm |
| Length | 286mm |
| Flow rate | 9 lpm |
| Temperature limiter | 41°C |
| Finish | Chrome-plated brass |
