• Liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• For mounting behind fixed mirror on site.
• One-hand operated and non-drip soap pump with 200 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard liquid soaps or hand lotions. Accessible for refilling through spring stop pin and by removing from below.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
  Depth of substructure installation: min. 120 mm
  Height above vanity unit: min. 160 mm
• Delivery includes fixing material and self-adhesive information label „Soap“.

• Weight (in kg): 0,5

Standardomadused:

120° pöördepiiraja
Keraamiline tööorgan
3/4" ühendus.
Standardne tsentrite vahe 150 mm Varustatud ilukatete ja ekstsentrikutega. 1500 mm dušivoolik metallkattega.

Roostevaba teras

poleeritud

Tootja FROST, Taani

kõrgus 48mm

pikkus 200mm

sügavus 120mm

kaal 1 kg

448 x 1348 x 220 mm
1 paper roll / 48 l

• Combination consisting of a sensor paper roll dispenser (mains-operated) and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Paper roll dispenser with touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Mains-operated 230 V / 50 Hz; power rating 7 Watt; mains cable on site. TÜV/GS-tested and certified.
• Designed for one paper roll with dimensions:
  Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Waste bin equipped with removable mesh basket.
  Capacity approx. 48 l.
• Accessible through lockable doors.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With six screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 25,8
