Water inlet | G 1/2" |
Water pressure | 2 – 6 Bar, recommended 3 Bar |
Outlet | d = 40 mm |
Inner dimensions of sink | d = 290 mm |
Weight | 20 kg |
Питьевые фонтаны

AFO 04
suspension drinking fountain
AFO 04 is a stainless-steel drinking fountain of a modern design. It is manufactured with a double surface finish: matt bowl (blasted with ballotini) and brushed casing. Thanks to its interesting appearance, it particularly suits public spaces, such as sports facilities, parks, squares, business centres, fitness and wellness centres, but also schools and kindergartens.
Similarly to AFO 01, the drinking fountain is operated with a push valve. Water is flowing while the valve is pushed and for a preset time after its release, in which way the nozzle is rinsed.
The water inlet is through a flexible hose; siphon trap is made of a flexible coupling. The flexible design of the water inlet and outlet enables variable and trouble-free connection of the fountain as well as its simple dismounting.
The AFO 04 drinking fountain is made from stainless steel of the AISI 304 class; the AFO 04.CL drinking fountain is made from steel of the AISI 316 class.
Package contents
- stainless steel casing
- press valve
- corner valve with filter
- fixing bar
- siphon
- connecting hose
- anchoring material
Water inlet | G 1/2" |
Water pressure | 2 - 6 Bar (recommended 3 Bar) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
- Set-up water inlet - pipe G1/2“.
- Set-up drainage d = 40 mm.
AFO 02 - IIstainless steel free-standing drinking fountain (indoor/outdoor)
AFO 02-II is a stainless steel drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The drinking fountain is to be placed in an open space. It is made up of an anchoring part intended for embedding in concrete and the column itself with a press valve and nozzle. These parts are connected by means of 3 screws and the upper part can be, therefore, easily dismounted in case of necessity (e.g. during winter).
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 02-II stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
Drinking fountain AFO 02-II is manufactured from the stainless steel AISI 304. AFO 02.CL-II is made of the stainless steel AISI 316 and is suitable for places with higher concentration of chlorine.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).Detail of the bowl
Package contents
- stainless steel column and cone with nozzle
- press valve
- anchoring construction
- flexible hose siphon
- connecting hoses
- anchoring material
- Set-up water inlet - pipe G 1/2“
- Set-up drainage d = 40 mm
- Prepared alcove for embedding (concreting) in the base construction
AFO 01.SL
drinking fountain with spout for filling bottles designed to stand and to be attached to wall
AFO 01.SL is a drinking fountain with spout for filling bottles designed to stand and to be attached to wall. Water runs for the time for which the valve is pressed plus the pre-set period after it is released; thus the jet can be rinsed. Second pressure valve serves for bottle filling.
In standard version the fountain is produced with a niche suitable for filling the bottle of 0.7 l. Fliountain with a niche for filling the botlles of 1.5 l can be made on order.
Water supply is provided by a flexible hose, trap comprises an elastic flexible couple. Flexible design of water supply and outflow allows variable and easy connection of the drinking fountain as well as its dismounting.
TAutomatic drinking fountain (with a sensor) can be supplied per order.
AFO 01.SL is manufactured from the stainless steel AISI 304. Other materials (e.g. AISI 316) possible on order.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).
Package contents
- Stainless housing with cone
- Pressure valve with jet
- Pressure valve for bottle filling
- Flexible hose outflow
- Fixing and connecting material
dimensions | 330 x 900 x 365 mm |
water outlet | d = 40 mm |
water inlet | G 1/2" |
water pressure | 2 - 6 Bar, recommended 3 Bar |
weight | 12 kg |
- Set up water outlet d = 40 mm
- Set up water inlet G 1/2"
AFO 01.Yst. steel sensor controlled drinking fountain
AFO 01.Y is st. stainless wall hung drinking fountain controlled by sensor. Water runs after disrupting the scanning zone.
Fountain is made by welding all components together.
Fountain is suppplied with safety power 12 V, 50 Hz from power supply ZAC (AFO 01.Y) or with 4x AA battery (AFO 01.YB).
Material is standardly st. steel AISI 304 or can be AISI 316 (AFO 01.Y.CL or AFO 01.YB.CL).
St. steel driking fountain AFO 01.Y is based on favourite model AFO 01 with manual control.
The sensor, located on the right side of the fountain, is reacting on the approach of the user. Water starts to run from the nozzle, located in the middle of the fountain bowl, and runs over the time when the user´s head is in the scanning zone (max. 30 sec.) + preset time (max. 4 sec.) to clean the nozzle.
Package contents
- st. steel drinking fountain
- nozzle
- sensor and electronic
- electromagnetic valve
- connecting flexible hose
- corner valve with filters
- siphon
- mounting material
water inlet | G 1/2" |
water pressure | 1 - 10 Bar (AFO 01.Y; AFO 01.Y.CL) |
2 - 8 Bar (AFO 01.YB; AFO 01.YB.CL) | |
outlet | d = 40 mm |
bowl inner dimension | d = 245 mm |
weigth | 4 kg |
suppply | 12 V, 50 Hz (AFO 01.Y; AFO 01.Y.CL) |
6 V - 4 x AA battery (AFO 01.YB; AFO 01.YB.CL) | |
power supply | ZAC 1/20 (max. 3 x AFO 01.Y ; AFO 01.Y.CL) |
Wall-mounted SD drinking fountain
Ref. 180800
Wall-mounted drinking fountain.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm.
Rounded edges prevent injury.
Supplied with bubbler tap: chrome-plated, instant shut-offand adjustable flow rate, inlet M3/8".
Flat perforated waste, without screws:easy to clean and vandal-resistant.
Recessed horizontal water outlet.
Waste outlet 1¼" trap.
Supplied with fixing elements.Weight: 2.4kg.
TECHNICAL FEATURES
Wall-mounted SD drinking fountain
Ref. 180800
Height | 150mm |
---|---|
Length | 320mm |
Width | 320mm |
Thickness | 1.2mm |
Finish | 304 polished satin stainless steel |
> Working pressure :
1 to 5 bar
> Flow :
3 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design
> Flow time :
15 seconds (± 5 sec.)
> Hydraulic supply :
M G 1/2" (15x21) - Cold water
> Thermal resistance :
Resistant to a temperature of 75°C for 30 minute thermal shock
> Security :
Interchangeable head and non-turnable push-button Non-removable, wear-proof coloured marker
> Delivered with :
Instruction manual
> Standards & approvals :
Acoustic class II
Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design
> Flow time :
15 seconds (± 5 sec.)
> Hydraulic supply :
M G 1/2" (15x21) - Cold water
> Thermal resistance :
Resistant to a temperature of 75°C for 30 minute thermal shock
> Security :
Interchangeable head and non-turnable push-button Non-removable, wear-proof coloured marker
> Delivered with :
Instruction manual
> Standards & approvals :
Acoustic class II
Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
Presto 504 veekraan+rosett isesulguv 15 sek 1/2" külm, antiblock
> Working pressure :
1 to 5 bar
> Flow :
3 l/min at 3 bar - 4-positions flow adjustment device Anti-water-hammering design
Vandalism proof and anti-clogging spout
> Flow time :
Presto 504 водяной кран самовыключающийся 15 sek 1/2" холодная, antiblock
15 seconds (± 5 sec.)
> Hydraulic supply :
M G 3/8" (12x17) - Premixed water
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Interchangeable head and non-turnable push-button
Non-removable, wear-proof coloured marker
Patented anti-blocking "S" system to avoid the water to flow continuously
> Delivered with :
Instruction manual
> Standards & approvals :
Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design
> Flow time :
7 seconds
> Hydraulic supply :
M G 1/2" (15x21) - Cold water
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Interchangeable head and anti-rotation push-button Non-removable, wear-proof coloured marker
> Delivered with :
Instruction manual
> Standards & approvals :
Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
Range: Washbasin single self-closing tap
Ref: 66305 - PRESTO NEO S® Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - hot or premixed water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66220 - PRESTO NEO S® Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - cold water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66105 - PRESTO NEO Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - hot or premixed water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66035 - PRESTO NEO Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
150 15 189
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - cold water
> Dimensions :
150mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66030 - PRESTO NEO Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - cold water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
> Working pressure: 1 to 5 bar
> Flow: 3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time: 7 seconds
> Hydraulic supply: G 1/2" x 15 - cold water
> Dimensions : 150mm projection
> Thermal resistance: This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety: With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with: 1 Installation manual
> Standards / Approvals: Stainless steel body (304 L) Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Presto P504 kroomitud toru pikkendus L100mm G 1/2" SV
Product Information:
390x700mm
100L
397,00 €
390x700mm
100L
400,00 €
AFO 04
suspension drinking fountain
AFO 04 is a stainless-steel drinking fountain of a modern design. It is manufactured with a double surface finish: matt bowl (blasted with ballotini) and brushed casing. Thanks to its interesting appearance, it particularly suits public spaces, such as sports facilities, parks, squares, business centres, fitness and wellness centres, but also schools and kindergartens.
Similarly to AFO 01, the drinking fountain is operated with a push valve. Water is flowing while the valve is pushed and for a preset time after its release, in which way the nozzle is rinsed.
The water inlet is through a flexible hose; siphon trap is made of a flexible coupling. The flexible design of the water inlet and outlet enables variable and trouble-free connection of the fountain as well as its simple dismounting.
The AFO 04 drinking fountain is made from stainless steel of the AISI 304 class; the AFO 04.CL drinking fountain is made from steel of the AISI 316 class.
Package contents
- stainless steel casing
- press valve
- corner valve with filter
- fixing bar
- siphon
- connecting hose
- anchoring material
Water inlet | G 1/2" |
Water pressure | 2 - 6 Bar (recommended 3 Bar) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
- Set-up water inlet - pipe G1/2“.
- Set-up drainage d = 40 mm.
Питьевой фонтан FP-004 крепление к стене, Н/Р сталь
AFO 02 - IIstainless steel free-standing drinking fountain (indoor/outdoor)
AFO 02-II is a stainless steel drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The drinking fountain is to be placed in an open space. It is made up of an anchoring part intended for embedding in concrete and the column itself with a press valve and nozzle. These parts are connected by means of 3 screws and the upper part can be, therefore, easily dismounted in case of necessity (e.g. during winter).
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 02-II stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
Drinking fountain AFO 02-II is manufactured from the stainless steel AISI 304. AFO 02.CL-II is made of the stainless steel AISI 316 and is suitable for places with higher concentration of chlorine.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).Detail of the bowl
Package contents
- stainless steel column and cone with nozzle
- press valve
- anchoring construction
- flexible hose siphon
- connecting hoses
- anchoring material
- Set-up water inlet - pipe G 1/2“
- Set-up drainage d = 40 mm
- Prepared alcove for embedding (concreting) in the base construction
Water inlet | G 1/2" |
Water pressure | 2 – 6 Bar, recommended 3 Bar |
Outlet | d = 40 mm |
Inner dimensions of sink | d = 290 mm |
Weight | 20 kg |
Питьевой фонтан Portinox FP-002 крепление к стене, до пола Н/Р сталь
Питьевой фонтан Portinox FP-003 для питья и заполнения бутылок, крепление к стене, до пола Н/Р сталь
855,00 €
650,00 €
AFO 01.SC
drinking fountain with cooling designed to stand and to be attached to wall
AFO 01.SC is a drinking fountain with cooling designed to stand and to be attached to wall. User can select between uncooled water and water running through a flow cooler. The fountain is operated by means of two piezo-buttons – resistant solution. Facility keeper can set a time period after which the water flow automatically stops.
The product contains a flow cooler. It is not a design with cooled tank only where – after the pre-cooled amount of water is pumped out – the user has to wait for the next charge to be cooled.
Flexible design of water supply and outflow allows variable and easy connection of the drinking fountain as well as its dismounting.
ttles
Automatic drinking fountain (with a sensor) can be supplied per order.
AFO 01.S is manufactured from the stainless steel AISI 304.
Other materials (e.g. AISI 316) possible on order. For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).
Package contents
- Stainless housing with cone
- Electronics and control piezo-buttons
- Water supply and electromagnetic valves
- Flow cooler
- Flexible hose outflow
- Fixing and connecting material
dimensions | 330 x 900 x 365 mm |
water outlet | d = 40 mm |
water inlet | G 1/2" |
water pressure | 0,2 – 0,6 MPa, recommended 0,3 MPa |
power supply | 230 V, 50 Hz |
power input | 820 W |
weight | 24 kg |
- Set up water outlet d = 40 mm
- Set up water inlet G 1/2"
- Electric socket 230 V, or electric cable CYKY 3C x 1,5
AFO 01.S
stainless steel drinking fountain with pressure valve designed to stand and to be attached to wall
AFO 01.S is a drinking fountain of stainless steel with pressure valve designed to stand and to be attached to wall. Water runs for the time for which the valve is pressed plus the pre-set period after it is released; thus the jet can be rinsed.
Water supply is provided by a flexible hose, trap comprises an elastic flexible couple. Flexible design of water supply and outflow allows variable and easy connection of the drinking fountain as well as its dismounting.
Automatic drinking fountain (with a sensor) can be supplied per order.
AFO 01.S is manufactured from the stainless steel AISI 304. Other materials (e.g. AISI 316) possible on order. For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).
Package contents
- Stainless housing with cone
- Pressure valve with jet
- Flexible hose outflow
- Fixing and connecting material
dimensions | 330 x 900 x 365 mm |
outlet | d = 40 mm |
water inlet | G 1/2" |
water pressure | 0,2 – 0,6 MPa, recommended 0,3 MPa |
weight | 12 kg |
- Set up water outlet d = 40 mm
- Set up water inlet G 1/2"
AFO 01 stainless steel wall-mounted drinking fountain
AFO 01 is a stainless steel wall-mounted drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 01 stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
AFO 01 is made of stainless steel AISI 304.
AFO 01.CL is made of stainless steel AISI 316 and is suitable into the areas with higher concentration of chlorine (e.g. swimming pools).
Sensor-controlled fountain possible made to order.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).
Package contents
- stainless steel sink with casing
- press valve
- corner valve with filter
- flexible hose siphon
- fixing bar
- connecting hoses
- anchoring material
Water inlet | G 1/2" |
Water pressure | 0,2 – 0,6 MPa (recommended 0,3 MPa) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
