298 x 1198 x 140 mm
ca. 750 paper towels / 13 l

• Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Can be installed flush with wall or tiles.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 750 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Waste bin equipped with removable mesh basket. Capacity approx. 13 l.
• Accessible through lockable, continuous, double-skin door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 1200 x 140 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 18,2

Nova2 Care

> Working pressure :

1 to 5 bar

> Flow :

5 l/min at 3 bar with integrated flow regulator Anti-water-hammering design

> Flow time :

Adjustable by washer 30 second (-10/+5seconds) timer

> Hydraulic supply :

Inlet M G 1/2" (15x21) - Cold or premixed water

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Patented anti-blocking "S" system to avoid the water to flow continuously Non-removable, wear-proof red marker

> Delivered with :

2 washers for flow time adjustment 1 Flat gasket
1 Nut 1/2’’ (15x21)
1 patte à vis

1 Rose

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12165
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

70 x 270 x 120 mm
700 ml tank

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• One-hand operated disinfectant pump with 700 ml tank.
• Designed for standard disinfectants for hands.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,4
