Water inlet | G 1/2" |
Water pressure | 2 – 6 Bar, recommended 3 Bar |
Outlet | d = 40 mm |
Inner dimensions of sink | d = 290 mm |
Weight | 20 kg |
Аксессуары WC подборки ( контора, офис, туалет)

Alamgrupid
-
Аксессуары для дома, кухни и ванной - золото (подборка)
-
Аксессуары для дома, кухни и ванной-чёрные (подборка)
-
Аксессуары для дома, кухни и ванной, WC белые (подборка)
-
Аксессуары бронза
-
Аксессуары медь (подборка)
-
Аксессуаары RAL
-
Аксессуары с установкой в шкаф, за зеркало
-
Аксессуары Н/Р сталь (подборка)
-
Аксессуары Н/Р сталь , полированные
-
Аксессуары Н/Р сталь, кислотостойкая AISI316
-
Многофункциональные комплекты
-
Аксессуары утопленные в стену
-
Простое решение (подборка)
-
Мебель для офиса
-
Настенные часы
-
Wagner Ewar P-Linе
-
Wagner Ewar A-Linе
-
Организация места для стаканчиков
WC paberi suure rulli hoidik
R/V teras AISI 303, satiin
Wagner Ewar
WC paberi suure rulli hoidik
R/V teras AISI 303, satiin
Wagner Ewar
WC paberi suure rulli hoidik
R/V teras AISI 303, satiin
Wagner Ewar
Tööpinda läbiv rõngas, R/V teras
AISI 304, poleeritud
192,00 €
AFO 04
suspension drinking fountain
AFO 04 is a stainless-steel drinking fountain of a modern design. It is manufactured with a double surface finish: matt bowl (blasted with ballotini) and brushed casing. Thanks to its interesting appearance, it particularly suits public spaces, such as sports facilities, parks, squares, business centres, fitness and wellness centres, but also schools and kindergartens.
Similarly to AFO 01, the drinking fountain is operated with a push valve. Water is flowing while the valve is pushed and for a preset time after its release, in which way the nozzle is rinsed.
The water inlet is through a flexible hose; siphon trap is made of a flexible coupling. The flexible design of the water inlet and outlet enables variable and trouble-free connection of the fountain as well as its simple dismounting.
The AFO 04 drinking fountain is made from stainless steel of the AISI 304 class; the AFO 04.CL drinking fountain is made from steel of the AISI 316 class.
Package contents
- stainless steel casing
- press valve
- corner valve with filter
- fixing bar
- siphon
- connecting hose
- anchoring material
Water inlet | G 1/2" |
Water pressure | 2 - 6 Bar (recommended 3 Bar) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
- Set-up water inlet - pipe G1/2“.
- Set-up drainage d = 40 mm.
AFO 02 - IIstainless steel free-standing drinking fountain (indoor/outdoor)
AFO 02-II is a stainless steel drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The drinking fountain is to be placed in an open space. It is made up of an anchoring part intended for embedding in concrete and the column itself with a press valve and nozzle. These parts are connected by means of 3 screws and the upper part can be, therefore, easily dismounted in case of necessity (e.g. during winter).
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 02-II stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
Drinking fountain AFO 02-II is manufactured from the stainless steel AISI 304. AFO 02.CL-II is made of the stainless steel AISI 316 and is suitable for places with higher concentration of chlorine.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).Detail of the bowl
Package contents
- stainless steel column and cone with nozzle
- press valve
- anchoring construction
- flexible hose siphon
- connecting hoses
- anchoring material
- Set-up water inlet - pipe G 1/2“
- Set-up drainage d = 40 mm
- Prepared alcove for embedding (concreting) in the base construction
AFO 01.Yst. steel sensor controlled drinking fountain
AFO 01.Y is st. stainless wall hung drinking fountain controlled by sensor. Water runs after disrupting the scanning zone.
Fountain is made by welding all components together.
Fountain is suppplied with safety power 12 V, 50 Hz from power supply ZAC (AFO 01.Y) or with 4x AA battery (AFO 01.YB).
Material is standardly st. steel AISI 304 or can be AISI 316 (AFO 01.Y.CL or AFO 01.YB.CL).
St. steel driking fountain AFO 01.Y is based on favourite model AFO 01 with manual control.
The sensor, located on the right side of the fountain, is reacting on the approach of the user. Water starts to run from the nozzle, located in the middle of the fountain bowl, and runs over the time when the user´s head is in the scanning zone (max. 30 sec.) + preset time (max. 4 sec.) to clean the nozzle.
Package contents
- st. steel drinking fountain
- nozzle
- sensor and electronic
- electromagnetic valve
- connecting flexible hose
- corner valve with filters
- siphon
- mounting material
water inlet | G 1/2" |
water pressure | 1 - 10 Bar (AFO 01.Y; AFO 01.Y.CL) |
2 - 8 Bar (AFO 01.YB; AFO 01.YB.CL) | |
outlet | d = 40 mm |
bowl inner dimension | d = 245 mm |
weigth | 4 kg |
suppply | 12 V, 50 Hz (AFO 01.Y; AFO 01.Y.CL) |
6 V - 4 x AA battery (AFO 01.YB; AFO 01.YB.CL) | |
power supply | ZAC 1/20 (max. 3 x AFO 01.Y ; AFO 01.Y.CL) |
268 x 268 x 300 mm
268 x 268 x 300 mm
268 x 268 x 300 mm
268 x 268 x 300 mm
268 x 268 x 300 mm
314 x 314 x 432 mm
314 x 314 x 432 mm
314 x 314 x 432 mm
314 x 314 x 432 mm
314 x 314 x 432 mm
314 x 314 x 631 mm
314 x 314 x 631 mm
314 x 314 x 631 mm
314 x 314 x 631 mm
7012
Reframe | Soap shelf and shower wiper
Soap shelf and shower wiper Brass
Unique soap shelf with hidden magnets in the wall fitting to give the wiper a permanent, functional and practical home.
The soap shelf is made of a strengthened steel plate with a groove to drain the water off it. Around the edge is a thin laser-cut ‘anti-slip’ barrier, to help stop shampoo and other bathroom products sliding off the shelf when it is wet.
The wiper has just two parts – a high-quality silicone element and a strengthened steel frame. This design distributes the pressure quite evenly across the whole surface and ensures that it is cleaned effectively and consistently. The wiper has silicone bumpers on the ends, to protect tiles and other surfaces from scratches. The silicone element is very hard-wearing and lasts a long time.
The pack contains fittings, screws and an Unbraco key for assembly.
7013
Reframe | Soap shelf and shower wiper
Soap shelf and shower wiper Copper
Unique soap shelf with hidden magnets in the wall fitting to give the wiper a permanent, functional and practical home.
The soap shelf is made of a strengthened steel plate with a groove to drain the water off it. Around the edge is a thin laser-cut ‘anti-slip’ barrier, to help stop shampoo and other bathroom products sliding off the shelf when it is wet.
The wiper has just two parts – a high-quality silicone element and a strengthened steel frame. This design distributes the pressure quite evenly across the whole surface and ensures that it is cleaned effectively and consistently. The wiper has silicone bumpers on the ends, to protect tiles and other surfaces from scratches. The silicone element is very hard-wearing and lasts a long time.
The pack contains fittings, screws and an Unbraco key for assembly.
7014
Reframe | Soap shelf and shower wiper
Soap shelf and shower wiper Black
Unique soap shelf with hidden magnets in the wall fitting to give the wiper a permanent, functional and practical home.
The soap shelf is made of a strengthened steel plate with a groove to drain the water off it. Around the edge is a thin laser-cut ‘anti-slip’ barrier, to help stop shampoo and other bathroom products sliding off the shelf when it is wet.
The wiper has just two parts – a high-quality silicone element and a strengthened steel frame. This design distributes the pressure quite evenly across the whole surface and ensures that it is cleaned effectively and consistently. The wiper has silicone bumpers on the ends, to protect tiles and other surfaces from scratches. The silicone element is very hard-wearing and lasts a long time.
The pack contains fittings, screws and an Unbraco key for assembly.
7032
Reframe | Shower wiper
Shower wiper Brass
Separate shower wiper and wall mount with integrated magnets to keep the wiper in place. The wiper consists of two parts; a reinforced steel frame and a high quality silicone blade. This construction ensures an effective and even cleaning of all surfaces. Built in ’bumpers’ on all sides protect your tiles from scratches and marks. The silicone element is very hard-wearing and lasts a long time.
