Intra L1 Н/Р сталь раковина, с задней стенкой 490x390x245mm
Бренд:
Единица: шт
Время доставки: 14-21 день
«Мои вкусы просты: я легко довольствуюсь лучшим».
Bucket sink in stainless steel for wall mounting. Supplied with stainless steel wall panel, supporting bracket and 3 1/2" x 2" waste with plug and overflow.
DESCRIPTION
MONOBLOCO 700 PMR WC pan with cistern
Ref. 110790
Floor-standing WC pan with dual flush cistern 3L/6L, 370 x 895 x 700mm.
700mm elongated pan for better comfort for people with reduced mobility.
Bacteriostatic 304 stainless steel. Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim. Water supply can be recessed from below or exposed from the side (right/left).
Recessed horizontal or vertical waste outlet. Supplied with PVC pipe.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick to install: 2 access panels with theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 22kg.
10-year warranty.
TECHNICAL FEATURES
MONOBLOCO 700 PMR WC pan with cistern
Ref. 110790
| Height | 895mm |
|---|---|
| Length | 700mm |
| Width | 370mm |
| Thickness | 1.5mm |
| Finish | Polished satin 304 stainless steel |
Overall dimension in mm Ø174 x 235 Inlet dimension in mm 1.5" Outlet dimension in mm 1.5" Material AISI 304 Material thickness in mm 1.5 Gross weight in kg 2.50
204,00 €
TECHNICAL FEATURES
LISO urinal divider for wall-mounting
Ref. 100590
| Height | 700mm |
|---|---|
| Length | 25/50mm |
| Width | 350mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
automatic washing system for wellingtons with jets - 12V, 50Hz
| Radius of sensor | 0 – 0,4 m |
| Water inlet | G 1/2“ |
| Water pressure | 0,3 – 1,0 MPa |
| Outlet | d = 32 mm |
| Inner dimensions of the trough | 250 x 400 x 280 mm |
| Electricity protection | IP 55 |
| Power supply | 12 V, 50 Hz |
| Power requirement | 10 VA |
| Source of power supply | ZAC 1/20 (max. 2 x AMO 01) |
| ZAC 1/50 (max. 5 x AMO 01) | |
| Weight | 18 kg |
- Set up water inlet as per picture
- Set up outlet d = 32 mm
- Set up cable for power supply – 12 V, 50 Hz from source of power supply ZAC
