> Working pressure:

1 to 5 bar

> Function:

Starts and stops automatically by hand detection
Sensor trigger suitable for PRM, elderly, children and disabled people

> Flow:

3l/min at 3 bar with integrated regulated anti-limescale aerator

> Hydraulic supply:

F G 3/8" (12x17) hoses

> Power supply:

Integrated 3V CR123A lithium batteries (x2)

> Material and colour finish:

Chrome-plated brass body with smooth inside body Chrome-plated molded metal cover

> Thermal resistance:

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security:

Anti-overflow security time set to 30 seconds preventing the water to flow continuously Automatic shutdown of solenoid valve in case of low battery or sensor damage
Duty flush 30 sec every 24h after last use (adjustable flow time and frequency)
Low battery alert (blinking led light)

Maximum temperature limitation with adjustable temperature stop

> Installation:

Recommended installation : 30 cm minimum between the sensor and the basin

> Delivered with:

1 Brass clamping nut, 1 Gasket and 1 Washer
2 PEX hoses with revolving nuts, NF check valves and filter gaskets 2 M M G 3/8" (12x17) stop valves
1 Self-adhesive sticker
1 Instruction manual

> Standards & approvals:

Brass body in accordance with NF EN1982, EN12164, NF EN 12165,

UBA list compliant

200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
