260 x 225 x 120 mm
approx. 300 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing open at the top; visible surfaces satin finished and brushed.
• Designed for approx. 300 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slot to indicate fill level.
• Refillable from the top.
• Mounting: For glueing or with three screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and first fill.

• Weight (in kg): 3,3

Components and Materials

Chromed brass bar Ø 25 mm, 1 mm thick, with a protection thickness of 9,4 µm nickel + 0,40 µm chrome.

Soap basket with chromed brass rods Ø 8 and 3 mm, with a protection thickness of 21 µm nickel + 0,20 µm chrome.

Chromed brass snap flange cover, 2 units with a protection thickness of 21 µm nickel + 0,20 µm chrome.

Press-formed mounting flanges, 2 units. Each flange incorporates 3 screws holes of Ø 5 mm for mounting on the wall

298 x 448 x 170 mm
23 l

• Waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Equipped with removable fabric stand bag in polypropylene, washable. Capacity approx. 23 l.
• Fabric stand bag replaces garbage bag.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 3,8

298 x 598 x 190 mm
ca. 34 l

• Waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed. Further available surfaces: see below.
• Equipped with removable fabric stand bag in polypropylene, washable. Capacity approx. 34 l.
• Fabric stand bag replaces garbage bag.
• Mounting: With three screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 5,6

350 x 580 x 210 mm
1 paper roll + 1 reserve roll

• Sensor paper roll dispenser with cabinet for reserve roll, battery-powered, in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm.
  Paper length and idle time adjustable.
  Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
• Designed for one paper roll and one reserve roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes in the back wall.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 12,4
