Range: SO'O

Ref: 56196 - Deck-mounted mixer sensor tap - Battery - Black and pink gold cover

Powered by TCPDF (www.tcpdf.org)

> Working pressure :

1 to 5 bar

> Flow :

3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design

> Hydraulic supply :

G 3/8" (12x17)

> Power supply :

6 V lithium battery (CRP2 type) in a casing placed within the tap body

> Material and colour finish :

Chrome-plated metal alloy components Injected molded metal body and cover Black finish with pink gold cover

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Temperature limited by adjustable stop
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation

> Delivered with:

2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
Instructions manual

> Standards & approvals :

200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

Range: Washbasin single self-closing tap

Ref: 65305 - PRESTO NEO S® Stainless Steel deck-mounted tap - 7 sec. (PRESTOGREEN)

> Working pressure:

1 to 5 bar

> Flow:

3 l/min at 3 bars - 4-position setting Anti water-hammer system

> Flow time:

7 seconds

> Hydraulic supply:

G 1/2'' x 40 - hot or premixed water

> Thermal resistance:

This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme

> Safety:

With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker

> Delivered with:

1 Nut for 12x14 tube
1 Fibre gasket
1 Stainless steel plain washer 1 Brass clamping nut
1 NBR washer
1 Installation manual

> Standards / Approvals:

Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
