Ø 30 x 274 mm
projection 90 mm

• Tabletop soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• Design height: 274 mm
  Outlet height: 203 mm
  Projection: 75 mm
• Non-drip soap pump with 500 ml soap bottle in plastics and pressure valve in stainless steel.
• Designed for standard liquid soaps.
• Refillable from above through detachable top part with bayonet lock.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 21-25 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 1,4

Käterätikuivati on valmistatud messingist. (brass)

Полотенцесушители выполнены из латуни

Sobib nii küttevee kui ka tarbevee süsteemi.

Подходят как для отопительной системы, так и для ГВС

Maksimaalne töörõhk on 600 KPa

Максимальное рабочее давление 600 KPa

Maksimaalne temperatuur 85°C

максимальная температура 85°C

Võimalikud viimistlused Chroom +...%

Возможные покрытия Chroom +...%

for all soap dispensers with soap bottle from 2005
60 x 105 x 70 mm

0,10 kg

SUITABLE FOR:

• L 109
• WP 101
• WP 102
• WP 173
• WP 174-2
• WP 208
• WP 500
• WP 510
• WP 550
• WP 575
• WP 600
• WP 650
• WP 5410
• WP 5415
• WP 5420
• WP 5425
• WP 5710
• WP 5715
• WP 5720
• WP 5725

350 x 448 x 210 mm
1 paper roll

• Sensor paper roll dispenser, battery-powered, in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
• Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 352 x 450 x 180 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 10,3
