1 Large: Ø 20 mm (0.78") x D 51.5 mm (2")
1 Medium: Ø 20 mm (0.78") x D 48 mm (1.8")
1 Small: Ø 20 mm (0.78")

General Description

•   Liquid soap dispenser of 1.5 L capacity, manufactured in stainless steel AISI 304, 0,8 mm thick, to be installed directly on the wall and lever-operated by means of an stainless steel lever.

•   Available in four finishes (white, black, bright and satin) these soap dispenser models have a functional, robust and trendy design that matches the new range of Mediclinics bathroom accessories. This allows this soap dispenser to blend into any space perfectly.

•   Suitable for high traffic facilities and for public use.

•   Dispenses liquid soaps or hydro-alcoholic gel. Surgical soaps and soaps with solid abrasive particles are not supported.

  Components & materials

  •   DJP0034: Stainless steel AISI 304, white epoxy finish.

  •   DJP0034C: Stainless steel AISI 304, bright finish.

  •   DJP0034CS: Stainless steel AISI 304, satin finish.

  •   DJP0034B: Stainless steel AISI 304, black epoxy finish.

  •   Level display in the front part that constantly indicates the level of soap available inside the soap dispenser.

  •   Inner plastic tank that prevents oxidation and that can be easily removed for cleaning and disinfection purposes.

  •   Lever made in stainless steel.

  •   Anti-drip corrosion resistant valve that dispenses 1.5 ml of soap per service. This anti-drip valve, which dispenses liquid soap, is easily interchangeable with the valves of the other soap dispensers of the same line.

  •   Hinged cover for operator convenience and speed of service.

  •   Opening on top with provided Mediclinics key that allows soap refill.

  •   It is mounted on the wall by means of four Ø4 stainless steel screws (provided) with their corresponding Ø 6mm plastic plugs (also provided).

  •   It is recommended to use liquid soaps or disinfectant gel soaps (maximum of alcohol content of 85 %) with a density between 0.9 and 1.35 kg/dm3 and a maximum viscosity of 3,000 cps.
