Ø 45 x 170 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

80 x 298 x 120 mm
400 ml foam soap concentrate

• Foam soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing with rounded vertical corners. Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• One-hand operated and non-drip foam soap pump.
• Designed for standard 400 ml foam soap concentrate.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and first fill with foam soap concentrate.

• Weight (in kg): 2,40

Quadra toilet brush, square. Available in 6 finishes. Q3026

Käterätikuivati on valmistatud messingist. (brass)

Полотенцесушители выполнены из латуни

Käterätikuivati elektrielemendi kaitse IP67

Käterätikuivati elektrikätikuivatile IP44-IP55

Степень защиты электрического элемента IP67

Степень защиты электрического полотенцесушителя IP44-IP55

Maksimaalne temperatuur 60°C

максимальная температура 60°C

Võimalikud viimistlused Chroom +...%

Возможные покрытия Chroom +...%
