Delabie Be-line инвалидная ручка d35MM L500mm антрацит алюминий
Бренд:
Единица: шт
Время доставки: 14-21 день
«Мои вкусы просты: я легко довольствуюсь лучшим».
Description
Be-Line® anthracite straight grab bar Ø 35mm, L. 500mm
Ref. 511905C
Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
500mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.
Technical features
Be-Line® anthracite straight grab bar Ø 35mm, L. 500mm
Ref. 511905C
| Length | 500mm |
|---|---|
| Width to the wall | 38mm |
| Thickness | 3mm |
| Finish | Metallised anthracite powder-coated aluminium |
Metallised anthracite shelf for grab bars for showers
Ref. 511922C
Metallised anthracite shelf for grab bars, for showers.
Installed against the all on the bar.
Anti-theft locking screw.
Ideal for shower gel or soap.
2 hooks for gloves.
TECHNICAL FEATURES
Metallised anthracite shelf for grab bars for showers
Ref. 511922C
| Height | 71mm |
|---|---|
| Depth | 70mm |
| Length | 165mm |
White shelf for grab bars for showers
Ref. 511922W
White shelf for grab bars, for showers.
Installed against the all on the bar.
Anti-theft locking screw.
Ideal for shower gel or soap.
2 hooks for gloves.
TECHNICAL FEATURES
White shelf for grab bars for showers
Ref. 511922W
| Height | 71mm |
|---|---|
| Depth | 70mm |
| Length | 165mm |
600mm satii R/V teras
156,00 €
703,00 €
General description
-
Wall to wall grab bar with three support points, made of diameter 32 mm AISI 304 stainless steel tube, to be installed in the washbasins and toilets.
-
With snap flange covers to conceal the screws, helping to achieve a beautiful and sleek look and protecting the flange surfaces from damage, dust, moisture and foreign particles.
-
Ideal to design barrier-free accessibility, both domestic and commercial places, these grab bars help make the lives easier for the handicapped and elderly people.
-
Highest durability and rusting resistance.
-
Optionally, these bars can be electrically isolated by installing the electrical isolation Kit code KA0020.
-
These grab bars are supplied with a kit to fix the bar to a brick wall.
Components and materials
-
BFD600C: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, bright finish.
-
BFI600C: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, bright finish.
-
BFD600CS: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, satin finish.
-
BFI600CS: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, satin finish.
-
TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along the bends.
-
CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes for wall mounting.
-
SNAP FLANGE COVER: three units made of stainless steel AISI 304, 0.8 mm thick and Ø 82 mm. Each cover snaps over mounting flange to conceal mounting screws.
186,00 €
Wall mounted MINERALCAST PMR washbasin
Ref. 132306
Wall-mounted washbasin, 785 x 545 x 150mm.
With integral side grips, can be used to support user or as a towel rail.
Sleek and fluid lines.
MINERALCAST: a composite material consisting of natural minerals and polyester resin.
Suitable for use in public and commercial places and the healthcare sector.
Shallow washbasin ideal for people with reduced mobility.
Uniform, non-porous surface is easy to clean.
One-piece pressed washbasin, seam-free, for easy maintenance and better hygiene.
Warm to the touch.
With Ø 35mm central tap hole.
Without overflow.
Supplied with fixing elements.
White, RAL 9016.
Weight: 21.5 kg.
Be-Line drop-down support rail with leg, L. 650mm, white
Ref. 511962W
Be-Line drop-down support rail for people with reduced mobility.
In the lowered position use as a grab bar, as a support for standingand for assisting movement, for WCS or showers.
Allows side access in the raised position.
Removable: easy to remove with anti-theft locking system. Reduces the number of barsin a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Retained in upright position. Slowed down descent.
Aluminium tube.
Rounded profile Ø 42mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
Concealed fixings secured to wall by a 304 stainless steel plate, 5mm thick.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Leg provides additional reinforcement when wall fixings are not enough.
Dimensions: 650 x 825 x 120mm.
Leg height can be adjusted from 760 - 780mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.
TECHNICAL FEATURES
Be-Line drop-down support rail with leg, L. 650mm, white
Ref. 511962W
| Height | 210mm |
|---|---|
| Length | 650mm |
| Width | 120mm |
| Finish | Powder-coated matte white aluminium |
