Delabie встраеваемый в пол WC SHA XS squart антивандальный Н/Р сталь AISI304
SHA XS squat WC pan
Ref. 113710
Floor-recessed squat WC pan, 500 x 220 x 600mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness 1.2mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Bowl shape suitable for male and female use.
Non-slip foot area.
Vertical waste outlet: Ø 100mm.
Flushing system with one 304 stainless steel spreader.
Weight: 5kg.
TECHNICAL FEATURES
SHA XS squat WC pan
Ref. 113710
Height | 30mm |
---|---|
Depth | 220mm |
Length | 600mm |
Width | 500mm |
Thickness | 1.2mm |
Finish | Polished satin 304 stainless steel |
Файлы
Wall-hung BCN S WC pan
Ref. 110112
Wall-hung WC pan, 360 x 375 x 550mm.
Compatible with all standard frame systems available on the market.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Dual finish: bright polished pan interior and polished satin exterior.
Stainless steel thickness: 1.5mm.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
Shrouded pan.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install from the front thanks to a stainless steel mounting frame.
Supplied with fixing plate and 6 theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
10-year warranty.
Weight: 12kg.
- Mirror in robust, germ-reducing and easy-care stainless steel mirror sheet metal (AISI 304).
- Mounting: With four Torx® locking screws.
- Delivery includes fixing material.
- Other dimensions available upon request.
- Weight (in kg): 2,7
201,30 €
KOMPACT washbasin and wall-hung WC combination
Ref. 160300
Combination unit: washbasin and suspended WC pan on right side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030003]
TECHNICAL FEATURES
KOMPACT washbasin and wall-hung WC combination
Ref. 160300
Height | 1000mm |
---|---|
Length | 735mm |
Width | 725mm |
Thickness | 2mm |
Finish | 304 polished satin stainless steel |
Single L stall urinal
Ref. 130200
Trough urinal for recessing in the floor.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm.
Rear water inlet. Central drainage.
Supplied with 1 stainless steel rinser and 1 flexible hose.
Water saving: optimal rinsing with 0.1 L/sec. per service i.e. 0.3L per use.
Waste outlet 11/2". Supplied with waste and integrated trap (ref. 785000).
Weight: 16.8kg.
TECHNICAL FEATURES
Single L stall urinal
Ref. 130200
Height | 1020mm |
---|---|
Length | 300mm |
Width | 600mm |
Thickness | 1.2mm |
Finish | 304 polished satin stainless steel |
Toilet seat
Ref. 101619
Polyethylene vandal-resistant model is easy to clean.
Colour: black.
With 304 stainless steel hinges.
For S21 and 700 WC models.
Supplied with fixing elements.
