91 x 259(221) x 98 mm

• Liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• For mounting behind fixed mirror on site.
• One-hand operated and non-drip soap pump.
• Designed for standard 500 ml or 950 ml disposable bottles of liquid soap or hand lotion. Accessible for refilling through spring stop pin and by removing from below.
• Also refillable with large container using the plug-in tank as an option.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
  Depth of substructure installation: min. 130 mm
  Height above vanity unit: min. 220(250) mm
• Delivery includes fixing material, self-adhesive information label „Soap“ and first fill with soap.

• Weight (in kg): 1,5

General description

 Fixed mirrors with a frame manufactured of stainless steel AISI 304, 1,0 mm thick.

 Mirror manufactured using a first quality glass 5 mm thick and it is backed with a medium density fiber shockabsorbing and waterproof board that reinforces the glass, making it stronger.  Model suitable for public use.

 Maximum durability and rusting resistance. Components & materials

 EP0350CS: 700 x 500 mm fixed mirror, with frame made of stainless steel AISI 304, 1,0 thick and satin finish.

 EP0450CS: 800 x 600 mm fixed mirror, with frame made of stainless steel AISI 304, 1,0 thick and satin finish.

 FRAME: made of stainless steel AISI 304, 1,0 thick. Unitized all welded construction. Edges and corners are burr free.  BACK PART: medium density fiber shock-absorbing and waterproof board, 10 mm thick that reinforces the glass, making it stronger.

 GLASS: standard glazing is No 1 quality, 5mm thick.  Stainless steel screws for brick walls are included with the mirrors.
