7447040, maximum loading permitted: 100 kgs,

> Working pressure:

1 to 5 bar

> Flow:

9 l/min at 3 bar - 4 positions flow adjustment device Anti-water-hammering design

> Flow time:

6 seconds (± 2 sec.)

> Hydraulic supply:

In-line water inlet
Arrivée et sortie M G 1/2" (15x21)

> Application:

Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit Complete kit

ready to install for ALLIA urinal reference Satolas
ready to install for DURAVIT urinal reference Ben / Katja / Pago // Jim / Starck 3 ready to install for IDEAL STANDARD urinal reference Esprit / San/ Remo ready to install for JACOB DELAFON urinal reference Kerax
ready to install for LAUFEN urinal reference Caprino / Como
ready to install for PORCHER urinal reference 2691
ready to install for ROCA urinal reference Mural / Urito
ready to install for SELLES urinal reference Euroline 8645 / 8620/ / Mistral ready to install for SPHINX urinal reference Eurobase 75 / 85 // Europa 85 ready to install for VILLEROY & BOCH urinal reference Targa/ pro
ready to install for VILLEROY & BOCH urinal reference Architect
ready to install for VITRA urinal reference Architek

> Delivered with:

1 PRESTO 12, urinal valve compatible NF 1 Equipped pipe 1/2" with water effect
1 Flat gasket
1 Nut

1 Loose wall flange Instruction manual

> Standards & approvals:

Brass body in accordance with EN 1982, EN 12164, EN 12165
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
