Automatic hand dryer.
Vandal-resistant model.
Automatically activated via optical cell.
360° rotating nozzle.
Metal thickness: 1.2mm.
Cover 304 stainless steel, bright polished finish.
Dimensions: 210 x 280 x 220mm.
Weight: 3.5kg.
Power: 2,000W. 50-60Hz.
Airflow: 95 l/second.
Low noise level: 68 dBA.
Maximum safety, Class II insulation(double electrical insulation), IP23.
CE marked, TÜV GS.

Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
190 lpm - M1 1/2".
