86 x 242 x 150 mm

• Sensor disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• For mounting behind fixed mirror on site.
• With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants. Accessible for refilling through spring stop pin and by removing from below.
• Note: Not approved for medical areas.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
  Depth of substructure installation: min. 185 mm
  Height above vanity unit: min. 270 mm
• Delivery includes fixing material, batteries and self-adhesive information label „Disinfectant“.

• Weight (in kg): 1,3

Ø 30 x 125 mm
projection 90 mm

• Tabletop soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• Design height: 128 mm
  Outlet height: 57 mm
  Projection: 75 mm
• Non-drip soap pump with 500 ml soap bottle in plastics and pressure valve in stainless steel.
• Designed for standard liquid soaps.
• Refillable from above through detachable top part with bayonet lock.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 21-25 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,9

Keevisõmbluseta korpus on aluste kinnitatud kahe vandaalikindla poldiga ja lukustatud spetsiaalse Saniflow võtmega

3mm paksune alumiinium alus

Tulekindlast plastist ventilaatorikamber

Termostaatlülitiga F-klassi universaalne harjadega mootor

Alumiiniumist tsentrifugaalne topeltsümmetriline õhuvõtuventilaatori tiivik

Elemendi on termokaitselüliti

Elektroisolatsioon klass 1

Kaitseklass IP23
