•  Towel shelf with bar, bright or satin finish and made in stainless steel AISI 304, for wall mounting.

•   The stainless steel AISI 304 construction protects the product against rust and ensures quality and longevity.

•   Model suitable for the hotel sector and for collectivities.

•   Concealed screws design.



  Components & materials

  •   AI0710C: AISI 304 stainless steel, bright finish.

  •   AI0710CS: AISI 304 stainless steel, satin finish.

  •   TOWEL SHELF: composed by 4 stainless steel AISI 304 cylindrical tubes Ø 9 mm, 0.8 mm thick.

  •   FLANGE AND POST: 2 units made in stainless steel AISI 304, 0.8 mm thick. Each flange has a concealed 1.6 mm stainless steel mounting bracket. All-welded construction. A stainless steel lock screw, at the bottom perimeter of flange, is used to lock the unit to the wall mounting plate. The mounting plate is secured to wall with two provided stainless steel screws.

  •   TOWEL BAR: composed by one-piece curved stainless steel AISI 304 tube Ø 6 mm, 0.8 mm thick.

  •   Screws and plugs for installation to the wall are provided.

Range : Timed flow single tap for shower
Ref : 27430 - PRESTO DL 400 SE® simple tap without stop valve

> Working pressure :

1 to 5 bar

> Flow :

6 l/min at 3 bar with integrated flow limiter Anti-water-hammering design
Fixed shower head with anti-limescale spikes

> Flow time :

30 seconds (± 5 sec.)

> Hydraulic supply :

G 3/4" (20x27) Top water inlet For cold or premixed water

> Material and colour finish :

Metal body injected molded
Profile extruded in aluminium-magnesium-silicon alloy 6060

> Thermal resistance :

Resistant to a temperature of 75°C for 30 minute thermal shock

> Security :

Patented anti-blocking "S" system to avoid the water to flow continuously

> Delivered with :

VBA screws and nylon plugs Filter gasket
Instruction manual

> Standards & approvals :

Acoustic class I
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
