Ручка 1000mm Н/Р сталь AISI304
600mm satii R/V teras
медь под сталь
Käetugi 738mm ületõstetav
R/V teras AISI304 harjatud
toru paksus 1,5mm
Pelavajutav äärikukate d 85mm
L454 x L869 mm
Grab bar, 90o angle to the right (BAD090C & BAD090CS) or to the left (BAI090C & BAI090CS) with snap flange cover, made of stainless steel AISI 304, for showers, baths and changing rooms.
These grab bars are very useful and highly recommended to achieve barrier-free accessibility both residential and public spaces.
Concealed screw mounting flanges.
Highest durability and rusting resistance.
Mounting hardware for brick wall is included for easy installation.
Components and materials
BAD090C & BAI090C: AISI 304 stainless steel, bright finish.
BAD090CS & BAI090CS: AISI 304 stainless steel, satin finish.
TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along
CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes
for wall mounting.
SNAP FLANGE COVER: three units made of stainless steel AISI 304, 1.5 mm thick and Ø 82 mm. Each cover snaps over mounting
flange to conceal mounting screws.
