448 x 598 x 120 mm
16 l

• Waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Equipped with removable mesh basket. Capacity approx. 16 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 7,9

Skyline handle CC224mm. Available in matt chrome, brushed and black. H2564

korpus

äravool

ilukate

Ø 45 x 170 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

Настенный смеситель Delabie SECURITHERM EP 2445LEP поворотный носик L200mm, Hygiene ручка L150mm

Seinasegisti Delabie SECURITHERM EP 2445LEP pöör.toruga L200mm, Hygiene käepide L150mm

SECURITHERM EP pressure-balancing basin mixer

Ref. 2445LEP
