400 x 298 x 120 mm
ca. 500 paper towels / sensor with 500 ml soap bottle

• Combination consisting of a sensor liquid soap dispenser and a paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
• Designed for standard 500 ml disposable bottles of liquid soap or hand lotion.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.

• Weight (in kg): 4,8

600 x 58 x 40 mm

• Towel rail in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Two concealed anti-theft wall disc mountings.
• Holder diameter 16 mm
  Towel rail diameter 12 mm
  Distance between mounting points 600 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,80
