LAB смеситель , F-200mm, WPH/WPC (15281009)

S P E C I F I CATIONS

Temperature range: 0-800C

Standard colour: black

Net weight: 1.6 kg

Dimensions: external 345 x 345 x 235mm (tolerance ± 1mm)

Injection moulded from polypropylene copolymer resin, with

a self-draining base. This square PP sink blends well into any

laboratory workbench. Extremely durable.

BROEN-LAB fully recirculating fittings ensure constant fresh

water with no dead legs even when the point-of-use valve is in closed position.

The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.

SPECIFICATIONS

Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792

Hose nozzle: Removable plastic

Headwork: Diaphragm type

Opening/closing function: 1 1/2 x 360°

Temperature range: 0-65°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.8 kg

MATERIALS WITH MEDIA CONTACT

Diaphragm: PTFE

Plastics: PP, PP-n, PVDF

Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- also available in ABS (1, 11/4 , 11/2)

Настольный кран с двумя вентилями на U-образной колонне

Технические характеристики

• Рукоятка: Полипропилен, с обозначением среды согласно EN13792

• Штуцер для шланга: Фиксированный полипропилен (можно открутить вручную, резьба: внешняя M19x1)

• Запорный механизм: Резиновый (рычажное управление запястьем: керамика)

• Открытие/закрытие: 2 × 360° (рычаг на 90°)

• Температурный диапазон: 0–65°C

• Макс. рабочее давление: 10 бар / 147 psi

• Испытательное давление: 1 × рабочее давление

• Вес: 2,5 кг

Материалы, контактирующие со средой

• Металлы: Латунь

• Пластик: PP (полипропилен)

• Уплотнения: EPDM

• Смазка: На силиконовой основе

• Керамика: Al2O3 96% (только рычаг)

Specifications
Handle: Polypropylene, with media indication according to EN13792 Hose nozzle: Fixed Polypropylene (can be unscrewed by hand, thread: male M19x1)
Headwork: Rubber (wrist action lever: ceramic)
Opening/closing function: 2 x 360° (wrist action lever: 90°) Temperature range: 0-65°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 2.5 kg

Materials with media contact
Metals: Brass
Plastics: PP
Sealing: EPDM
Lubricant: Silicone based
Ceramics: Al2O3 96% (wrist action lever only)
