298 x 360 x 120 mm
ca. 500 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• For mounting behind fixed mirror on site.
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
• With deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through spring-clip flap from below.
• Mounting: With four screws.
  Depth of substructure installation: min. 120 mm.
  Height above vanity unit: min. 160 mm.
• Delivery includes fixing material, self-adhesive information label „Paper“ and one pack of paper towels.

• Weight (in kg): 4,4

Korpus

Äravool

raam

ilurest

Normbau Inox Care Lift-up inva käepide ülestüstetav 2050050 vario, suspendable, L = 850mm, siena kinnitusega

Inox Care Lift-up support rail 2050050 vario, suspendable, L = 850mm, with base plate

Lift up support rail vario with base plate,
length 850mm, 32mm dia.,

made of stainless steel, material No. 1.4301 (A2 AISI 304), brushed finish, left or right hand application, space required in vertical position 193mm from wall, with adjustable brake, easy installation by mounting to a base plate.
Base plate, made of stainless steel for balanced wall mounting, concealed screw fixing, supplied without fixing screws and plugs, conform to German standard DIN 18040 1-2, maximum loading permitted: 125 kgs.
850mm length conform to German standard DIN 18040-1/2, Austrian standard ÖNORM B1600.

TÜV PRODUKT SERVICE certified.

Select appropriate fixing material to suit site conditions. Can be fitted with paper roll holder 2050 300 may be added at a later stage.

korpus

äravool

raam

ilukate
