Segistid ja kraanid roostevabast terasest
Range: Washbasin single self-closing tap
Ref: 65105 - PRESTO NEO Stainless Steel deck-mounted tap - 7 sec. (PRESTOGREEN)
120
G1/2" 100
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2'' x 40 - hot or premixed water
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker
> Delivered with:
1 Nut for 12x14 tube
1 Fibre gasket
1 Stainless steel plain washer 1 Brass clamping nut
1 NBR washer
1 Installation manual
> Standards / Approvals:
Stainless steel body (compliant with standards NF EN1982 / NF EN12164 / NF EN12165) Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66105 - PRESTO NEO Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - hot or premixed water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 65010 - PRESTO NEO Stainless Steel deck-mounted tap - 7 sec. (PRESTOGREEN)
120
G1/2" 100
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2'' x 40 - cold water
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Nut for 12x14 tube
1 Fibre gasket
1 Stainless steel plain washer 1 Brass clamping nut
1 NBR washer
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66035 - PRESTO NEO Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
150 15 189
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - cold water
> Dimensions :
150mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66030 - PRESTO NEO Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - cold water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 65305 - PRESTO NEO S® Stainless Steel deck-mounted tap - 7 sec. (PRESTOGREEN)
120
G1/2" 100
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2'' x 40 - hot or premixed water
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker
> Delivered with:
1 Nut for 12x14 tube
1 Fibre gasket
1 Stainless steel plain washer 1 Brass clamping nut
1 NBR washer
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66305 - PRESTO NEO S® Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - hot or premixed water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable red circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 65210 - PRESTO NEO S® Stainless Steel deck-mounted tap - 7 sec. (PRESTOGREEN)
120
G1/2" 100
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2'' x 40 - cold water
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Nut for 12x14 tube
1 Fibre gasket
1 Stainless steel plain washer 1 Brass clamping nut
1 NBR washer
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Range: Washbasin single self-closing tap
Ref: 66220 - PRESTO NEO S® Stainless Steel wall-mounted tap - 7 sec. (PRESTOGREEN)
G1/2
65 15 104
> Working pressure:
1 to 5 bar
> Flow:
3 l/min at 3 bars - 4-position setting Anti water-hammer system
> Flow time:
7 seconds
> Hydraulic supply:
G 1/2" x 15 - cold water
> Dimensions :
65mm projection
> Thermal resistance:
This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme
> Safety:
With S® antiblocking system to prevent blocking in continuous flow Interchangeable head and non-turnable push button to avoid premature wear Non-removable blue circled marker
> Delivered with:
1 Installation manual
> Standards / Approvals:
Stainless steel body (304 L)
Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
Valamusegist Wagner Ewar kõrge, pikk käepide Roostevabast terasest AISI303 harjatud
BASIN TAP WA 110-1
Ø 45 x 283 x 185 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,70
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925276 |
| highly polished | 932276 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 185 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA110-1
798,00 €
BASIN TAP WA 110-1
Ø 45 x 283 x 185 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,70
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925276 |
| highly polished | 932276 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 185 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA110-1
996,00 €
BASIN TAP WA 110-1
Ø 45 x 283 x 185 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,70
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925276 |
| highly polished | 932276 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 185 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA110-1
810,00 €
BASIN TAP WA 110
Ø 45 x 283 x 155 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,70
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925266 |
| highly polished | 932266 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 155 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA110
948,00 €
BASIN TAP WA 110
Ø 45 x 283 x 155 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,70
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925266 |
| highly polished | 932266 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 155 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA110
756,00 €
BASIN TAP WA 210
Ø 45 x 283 x 155 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
- Mounting: With one counternut.
- Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
- Weight (in kg): 2,00
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925267 |
| highly polished | 932267 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 155 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA210
1026,00 €
BASIN TAP WA 210-1
Ø 45 x 283 x 185 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
- Mounting: With one counternut.
- Delivery includes fixing material and three flexiblen, stainless steel covered connecting tubes.
- Weight (in kg): 2,00
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925277 |
| highly polished | 932277 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 185 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA210-1
1068,00 €
BASIN TAP WA 210
Ø 45 x 283 x 155 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
- Mounting: With one counternut.
- Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
- Weight (in kg): 2,00
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925267 |
| highly polished | 932267 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 155 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA210
834,00 €
BASIN TAP WA 210-1
Ø 45 x 283 x 185 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
- Mounting: With one counternut.
- Delivery includes fixing material and three flexiblen, stainless steel covered connecting tubes.
- Weight (in kg): 2,00
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 925277 |
| highly polished | 932277 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 185 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA210-1
876,00 €
BASIN TAP WA 200
Ø 45 x 170 x 155 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,90
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924267 |
| highly polished | 931267 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 155 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA200
642,00 €
BASIN TAP WA 200-1
Ø 45 x 170 x 185 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,90
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924277 |
| highly polished | 931277 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 185 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA200-1
684,00 €
BASIN TAP WA 200
Ø 45 x 170 x 155 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,90
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924267 |
| highly polished | 931267 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 155 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA200
786,00 €
BASIN TAP WA 200-1
Ø 45 x 170 x 185 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,90
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924277 |
| highly polished | 931277 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 185 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA200-1
834,00 €
BASIN TAP WA 100-1
Ø 45 x 170 x 185 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,60
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924276 |
| highly polished | 931276 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 185 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA100-1
740,00 €
BASIN TAP WA 100-1
Ø 45 x 170 x 185 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,60
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924276 |
| highly polished | 931276 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 185 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA100-1
750,00 €
BASIN TAP WA 100-1
Ø 45 x 170 x 185 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 140 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,60
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924276 |
| highly polished | 931276 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 185 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA100-1
599,00 €
BASIN TAP WA 100
Ø 45 x 170 x 155 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M22 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,60
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924266 |
| highly polished | 931266 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 155 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA100
558,00 €
BASIN TAP WA 500
50 x 172 x 161 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid rectangular stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
- High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M24 x 1 mm.
- Design height: 172 mm
Outlet height: 92 mm
Projection: 97 mm
Length of lever: 65 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 2,3
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924265 |
| highly polished | 931265 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid rectangular stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: 50 x 172 x 161 mm
Outlet height 92 mm
Projection 97 mm
Length of lever 65 mm
Article No. WA500
672,00 €
BASIN TAP WA 100
Ø 45 x 170 x 155 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below. - High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M22 x 1 mm.
- Design height: 171 mm
Outlet height: 87 mm
Projection: 98 mm
Length of lever: 40 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 1,60
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924266 |
| highly polished | 931266 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 155 mm
Outlet height 87 mm
Projection 98 mm
Length of lever 40 mm
Article No. WA100
702,00 €
BASIN TAP WA 500
50 x 172 x 161 mm
normal pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: normal pressure. Operating pressure 2–6 bar.
- Solid rectangular stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
- High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M24 x 1 mm.
- Design height: 172 mm
Outlet height: 92 mm
Projection: 97 mm
Length of lever: 65 mm - Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm
Surface thickness max. 40 mm - Mounting: With one counternut.
- Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
- Weight (in kg): 2,3
| AVAILABLE SURFACES | ORDER NUMBERS |
|---|---|
| satin finished (standard) | 924265 |
| highly polished | 931265 |
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid rectangular stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: 50 x 172 x 161 mm
Outlet height 92 mm
Projection 97 mm
Length of lever 65 mm
Article No. WA500
822,00 €
