Ref: 70804 - Wall-mounted mixer tap with 2 holes – upward spout
> THE PRODUCT BENEFITS
Resistant to intensive use Reinforced body / spout interface with double sliding bearings: no play and high endurance Robust spout: diameter 22 mm. Intuitive and ergonomic knobs: easy grip Hygiene: spout with smooth interior Wall version: facilitates cleaning and promotes optimal hygiene Product design High spout to let large containers pass Easy maintenance: presence of a slot under the red / blue patch allowing the passage of a screwdriver Ease of maintenance: availability of all spare parts Flow straightener to channel water and avoid lateral water splashes
> TECHNICAL SPECIFICATIONS > Model:
Wall-mounted mixer with spout above 360 ° swivel spout, 250 mm projection, height under spout 226 mm, diameter 22 mm. Spout thickness: 1.5 mm 1/4 turn ceramic head with flow rate 81L / min at 3 bar Interchangeable anti-tartar flow straightener
> Recommended working pressure:
1 to 5 bars
> Flow rate:
81L / min at 3 bar
> Hydraulic supply:
M1 /2'' M3 /4'' offset fittings supplied with rosettes
> Material and color of finish:
Chromed brass body and spout Material compliant with the "UBA" list
> Thermal resistance :
Withstands a temperature of 75 ° C for 30 minutes (in the context of thermal shock).
> Delivered with :
NF check valves 2 filters
> Standards and approvals:
Chromed brass body compliant with standards NF EN1982 / NF EN 12164 / NF EN 12165 Nickel-Chrome surface treatment according to NF EN12540 Resistance to neutral salt spray (NSS): 200 h according to NF ISO 9227
