Presto 504 veekraan isesulguv 15 sek 1/2" külm, antiblock

> Working pressure :

1 to 5 bar

> Flow :

3 l/min at 3 bar - 4-positions flow adjustment device Anti-water-hammering design
Vandalism proof and anti-clogging spout

> Flow time :

15 seconds (± 5 sec.)

> Hydraulic supply :

M G 3/8" (12x17) - Premixed water

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Interchangeable head and non-turnable push-button
Non-removable, wear-proof coloured marker
Patented anti-blocking "S" system to avoid the water to flow continuously

> Delivered with :

Instruction manual

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

> Working pressure :

1 to 5 bar

> Flow :

3 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design

> Flow time :

15 seconds (± 5 sec.)

> Hydraulic supply :

M G 1/2" (15x21) - Premixed water

> Thermal resistance :

Resistant to a temperature of 75°C for 30 minute thermal shock

> Security :

Interchangeable head and non-turnable push-button Non-removable, wear-proof coloured marker

> Delivered with :

Instruction manual

> Standards & approvals :

Acoustic class II
Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

> Working pressure :

1 to 5 bar

> Flow :

3 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design

> Flow time :

7 seconds

> Hydraulic supply :

M G 1/2" (15x21) - Cold water

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Interchangeable head and anti-rotation push-button Non-removable, wear-proof coloured marker

> Delivered with :

Instruction manual

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

> Working pressure :

1 to 5 bar

> Flow :

3 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design

> Flow time :

15 seconds (± 5 sec.)

> Hydraulic supply :

M G 1/2" (15x21) - Premixed water

> Thermal resistance :

Resistant to a temperature of 75°C for 30 minute thermal shock

> Security :

Interchangeable head and non-turnable push-button Non-removable, wear-proof coloured marker

> Delivered with :

Instruction manual

> Standards & approvals :

Acoustic class II
Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

> Working pressure :

1 to 5 bar

> Flow :

18 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design

> Flow time :

4-8 seconds

> Hydraulic supply :

M G 1/2" (15x21) - Cold water

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Interchangeable head and anti-rotation push-button Non-removable, wear-proof coloured marker

> Delivered with :

Instruction manual

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12156
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

18 1/2” 6 75°C 10YEARS ACS l/min sec

Presto P504 kroomitud toru pikkendus L100mm G 1/2" SV
