86 x 287(248) x 148 mm

• Sensor liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• For mounting behind fixed mirror on site.
• With EWAR® eModule touch-free operated and non-drip soap pump.
• Designed for standard 500 ml or 950 ml disposable bottles of liquid soap or hand lotion. Accessible for refilling through spring stop pin and by removing from below.
• Also refillable with large container using the plug-in tank as an option.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
  Depth of substructure installation: min. 185 mm
  Height above vanity unit: min. 250(280) mm
• Delivery includes fixing material, batteries, self-adhesive information label „Soap“ and first fill with soap.

• Weight (in kg): 2,2
