SLP 33RZ

Urinal Casa with cover with a radar flushing unit and integrated power supply, 230 V AC

Characteristics

economy flushing by 1 liter of water
easy installation
whole flushing unit is placed behind the urinal
system reacts only on the direct use of the urinal (it analyses changes, which are proceeded inside of the urinal, when a liquid is flowing through)
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 04 without the necessity to dismantle the urinal from the wall (acoustic setting indication)
automatic flushing after each 6 hours non-use
possibility to regulate a water flow by the ball valve
radar flushing unit recharges a water to the siphon after each flushing

Order number	01335
Code	SLP 33RZ

Supply specification

SLP 33RZ - Supply No. 01335 - ceramic urinal with the radar flushing unit, plastic mounting box with a brass screw coupling, electromagnetic valve and angle valve, inlet fitting with a rubber sealing, siphon, power supply

Technical information

Mounting box dimension: 140 x 140 x 75 mm
Operating voltage: 230 V AC/50 Hz
Recommended flow pressure: 0,1 - 0,6 MPa
Rate of flow: 18 l/min (inf. data)
Water inlet: male thread G 3/4“
Water outlet: inlet fitting with a rubber sealing

1243,55 € (-5%) 1309,00 €

Soodus

Köögivalamu Frame 1 kausi ja norutusega, kauss paremal

Tootekood: I-FR97SXR , Tarneaeg: 3-4 nädalad

General

Modulesize from (cm):	60
Size (mm):	970 x 510
Large bowl (mm):	520 x 380 x 180
Cut-out dimensions (mm):	950 x 490
Designer:	Halvor Thorsen/ Martin Krafft

887,40 € (-10%) 986,00 €

Soodus

Kombinatsioon läbi töötasapinna paberrätikute dosaator 250 paberrätikud, prügikast koos klapiga 11L R/V tears harjatud

Tootekood: WAG-WP511 , Tarneaeg: 14-21 päeva

COMBINATION PAPER TOWEL DISPENSER AND WASTE BIN WP 511

298 x 645 x 164 mm
ca. 250 paper towels / 11 l

Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
Further available surfaces: see below.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag- or c-fold.
Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through lockable front flap.
Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts can be replaced as modules.
Mounting: With four screws through key holes and one optional anti-theft hole in the back wall off-floor below vanity unit, or as an option with console or base for a surcharge.
Delivery includes fixing material and one pack of paper towels.

Weight (in kg): 8,5

AVAILABLE SURFACES	ORDER NUMBERS
satin finished (standard)	728050
highly polished	732050
(coloured) plastic powder - coating	728137

Suggested text for specifications:

Combination consisting of a paper towel dispenser and a waste bin in stainless steel (AISI 304) for under-counter mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Paper towel dispenser with deep-drawn paper removal opening, filling quantity approx. 250 paper towels. Accessible for refilling through lockable front flap. Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap. Keyed alike cylinder locks in corrosion-resistant zinc die-casting. Delivery includes fixing material and one pack of paper towels.

Dimensions: 298 x 645 x 164 mm

Article No. WP511

615,60 € (-5%) 648,00 €
