General description

•   White epoxy-coated grab bars curved in 90o, to be installed on the wall, with Polypropylene snap flanges and made of Ø 32 mm steel tube.

•   These grab bar make the daily life-management of not only the disabled and elderly people easier but also it is a great support for everybody who needs help with moving.

•   Especially designed to achieve barrier-free accessibility in bathrooms and public spaces.

•   With three snap flanges, made of white Polypropylene that provide a clean finished look hiding the mounting screws.

•   Easy to clean.

•   Optionally, they have a kit to avoid electrical conductivity (code KA0010).

•   Fixing screws for brick wall included.

  Components and materials

•   BAD090C & BAI090C: right hand grab bar made of steel, white finish.

•   BAD090CS & BAI090CS: left hand grab bar made of steel, white finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter

  along the bends.

•   CONCEALED MOUNTING FLANGE: three units made of steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes for wall

  mounting.

•   SNAP FLANGE COVER: three units made of Polypropylene, 1.5 mm thick and Ø 85 mm. Each cover snaps over mounting flange
