32 x 32 x 111 mm
projection 87 mm

• Tabletop soap dispenser, lockable, in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below
• Design height: 111 mm
  Outlet height: 62 mm
  Projection: 66 mm
• Non-drip soap pump with 500 ml soap container in plastics and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard liquid soaps.
• Refillable from above by unscrewing the top part, secured with hexagon socket screw.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 1,0

93 x 290 x 225 mm
1000 ml bottle

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• Half-open stainless steel housing; visible surfaces satin finished and brushed.
• Elbow-operated disinfectant pump, can be set to different levels and autoclaved.
• Designed for standard 1000 ml disposable bottles of disinfectant.
• Accessible for refilling from the front side. Lockable cover plate in stainless steel as an option for a surcharge.
• Further accessories for a surcharge: drip tray
• Wear parts can be replaced as modules.
• Mounting: With three screws through holes in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,2

Käterätikuivati Margaroli VENTO veele 400 kroomitud messing 585 × 600 mm

Käterätikuivati on valmistatud messingist. (brass)

Полотенцесушители выполнены из латуни

Sobib nii küttevee kui ka tarbevee süsteemi.

Подходят как для отопительной системы, так и для ГВС

Maksimaalne töörõhk on 600 KPa

Максимальное рабочее давление 600 KPa

Maksimaalne temperatuur 85°C

максимальная температура 85°C

Võimalikud viimistlused Chroom +...%

Возможные покрытия Chroom +...%

450 x 450 x 130 mm
400 ml foam soap concentrate / ca. 500 paper towels

• Mirror cupboard with integrated foam soap dispenser and paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed.
• Crystal mirror with all round 2 mm chamfer and frosted window for optional lighting set.
• Foam soap dispenser with one-hand operated and non-drip foam soap pump.
• Designed for standard 400 ml foam soap concentrate.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Lighting set available as an option.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, first fill with foam soap concentrate and one pack of paper towels.

• Weight (in kg): 11,0
