Delabie elektrooniline kraan eelsegatud veele 170mm 388035 M3/8" BINOPTIC TAP 230/12V matt must
BLACK BINOPTIC electronic tap
Ref. 388035
Deck-mounted electronic basin tap: Independent IP65 electronic control unit. 230/12V mains supply with transformer. Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm. Scale-resistant flow straightener. Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use). Active, infrared presence detection, sensor at the end of the spout optimises detection. Chrome-plated brass body. Matte black chrome finish. PEX flexible with filter and solenoid valve M3/8". Fixing reinforced by 2 stainless steel rods. Anti-blocking security. Spout with smooth interior and low volume of water (reduces bacterial development). Drop height: 170mm for semi-recessed washbasins. Suitable for people with reduced mobility.
Ref: 70814 - Wall-mounted column with 2 holes– rinsing head
> THE PRODUCT BENEFITS
Resistant to intensive use Spring flexibility Ergonomic hand shower with continuous flow function, and gripping surface limiting the risk of burns. Tip to absorb shocks. Locking hook to avoid MSDs (musculoskeletal disorders) Reinforced body / column interface Intuitive and ergonomic knobs: easy grip Product design Wall version: facilitates cleaning and promotes optimal hygiene Adjustable wall support PU sheath shower hose to avoid bacterial niches and facilitate cleaning Easy maintenance: presence of a slot under the red / blue patch allowing the passage of a screwdriver Ease of maintenance: availability of all spare parts
> TECHNICAL SPECIFICATIONS > Model:
1/4 turn ceramic head mixer Black M 1/2'' hand shower with grip surface limiting the risk of burns Shower flow regulated at 12L / min. User adjustable jet: concentrated or wetting. Anti-scale shower head. Locking hook for continuous flow. Integrated non-return valve. Guide spring for stainless steel hose Adjustable wall support, can be cut from 60 to 200 mm (from column to wall) Adjustable hand shower holder: left or right
> Recommended working pressure:
1 to 5 bars
> Shower flow:
12L /min at 3 bar
> Hydraulic supply:
G 1/2 '' (15x 21)
> Material and color of finish:
Body and column in chromed brass Injected metal hook Material compliant with the "UBA" list
> Thermal resistance :
Withstands a temperature of 75 ° C for 30 minutes (as part of thermal shock).
> Delivered with :
Eccentric rosettes 1 filter 1 stainless steel braided hose (hand shower) surrounded by a PU sheath, resistant to temperatures up to 90 ° C. Continuous operating temperature at 70 ° C maximum
> Standards and approvals:
Chromed brass body compliant with standards NF EN1982 / NF EN 12164 / NF EN 12165 Nickel-Chrome surface treatment according to NF EN12540 Resistance to neutral salt spray (NSS): 200 h according to NF ISO 9227
