Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
Suitable for flush horizontal under-counter mounting.
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
With deep-drawn paper removal opening for easy paper removal.
Designed for approx. 500 standard paper towels in zigzag- or c-fold. Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through lockable drawer.
Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
Wear parts can be replaced as modules.
Installation dimensions: 300 x 150 mm
Mounting: With screws on the inside.
Delivery includes fixing material and one pack of paper towels.
Weight (in kg): 5,6
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
727408
highly polished
731408
(coloured) plastic powder - coating
728128
Suggested text for specifications:
Paper towel dispenser in stainless steel (AISI 304) for flush horizontal under-counter mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. With deep-drawn paper removal opening, filling quantity approx. 500 paper towels. Accessible for refilling through lockable drawer. Keyed alike cylinder lock in corrosion-resistant zinc die-casting. Delivery includes fixing material and one pack of paper towels.
COMBINATION PAPER TOWEL- AND SOAP DISPENSER 950ML BOTTLE AND WASTE BIN WP 500
298 x 1348 x 120 mm ca. 250 paper towels / 950 ml soap bottle / 11 l
Combination consisting of a liquid soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Liquid soap dispenser with one-hand operated and non-drip soap pump.
Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
Also refillable with large container using the plug-in tank as an option.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
Inspection slots to indicate fill level.
Accessible for refilling through lockable front flap with fall protection.
Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 300 x 1350 x 110 mm
Mounting: With eight screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material, first fill with soap and one pack of paper towels.
Shelf is 18‑gauge (1.2mm), type 304 stainless steel, satin finish; 36" Long, 6" H, 8" D (915 x 150 x 205mm). Four anti-slip mop holders have spring-loaded rubber cam that grips handles 7⁄8" to 1 1⁄4" (20–30mm) diameter. Holds mops 8" (205mm) from wall. Three stainless steel rag hooks. Rod for wet rags below shelf.
