Stiilne ja funktsionaalne peeglikapp 4 funktsiooniga: peegel, kontaktivaba kraan, automaatne seebidosaator ja kätekuivati. Valmistatud kvaliteetsest 304 roostevabast terasest ja viimistletud mati musta melamiiniga.
Puutevaba hügieen: kõik funktsioonid aktiveeruvad infrapunandurite abil.
Kiire paigaldus: üks elektriühendus ja reguleeritavad kinnitused.
Tänapäevane disain: valgustatud piktogrammid ja musta klaasi detailid.
Funktsioonid:
Automaatne kraan: reguleeritav veevool (1,4–6 l/min) ja kaitse ummistumise vastu.
Seebidosaator: suur 5-liitrine paak, sobib vedelseebile.
Kätekuivati: kiire 360 km/h õhuvool, madal energiatarve ja müra (74 dBA).
Integreeritud LED-valgustus ja praktiline hoiuruum.
Mõõdud: 800 x 223 x 1,000 mm. Sobib suurepäraselt nii avalikku ruumi kui ka moodsasse kodusesse vannituppa.
Mirror cabinet with 4 functions
Ref. 510204 Mirror, hand dryer, soap dispenser and electronic tap
DESCRIPTION
Mirror cabinet with 4 functions
Ref. 510204
Mirror cabinet with 4 functions: mirror, electronic tap, soap dispenser and electrical hand dryer. 304 stainless steel designer cabinet with a matte black melamine finish. Touch-free for improved hygiene: soap dispenser, tap and hand dryer are activated automatically when hands are detected by infrared sensor. Quick and easy to install: - A single electrical connection for all the elements: mains supply with 230V / 50-60Hz. - Connects to the water supply from the top or from inside the cabinet. - Water connection in M3/8". - Concealed fixings. Mirror cabinet supplied with stainless steel screws for concrete or reinforced wood. - Adjustable hinges. Unit with 4 functions: 4mm thick glass mirror and black glass strip with illuminated pictograms. Automatic soap dispenser: - No-waste pump dispenser - Large capacity tank: 5 litres. - Suitable for vegetable-based liquid soap with a maximum viscosity of 3,000 mPa.s or specific foam soap. Electronic basin tap*: - Reduced stagnation solenoid valve. - Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm. - Scale-resistant flow straightener. - Duty flush (~60 seconds every 24 hours after the last use). - Stopcock. Air-pulse hand dryer: - High-speed. - Pulsed air at 360km/h. Airflow: 36 l/second. - Low energy consumption: 704W. - Noise level: 74 dBA. - Class I, IP23. - 3-year warranty. Basin lit by the LED strip. Vandal-resistant model with standard DELABIE key. Anti-blocking: stops automatically if used continuously. Internal storage shelf. Several cabinets can be installed side-by-side to create a mirror wall: linking screws are provided. Dimensions: 800 x 223 x 1,000mm. Weight: 39kg.
TECHNICAL CHARACTERISTICS
Mirror cabinet with 4 functions
Ref. 510204
Supply
Mains: 230V / 50-60Hz
Connector
M3/8"
Technology
Electronic
Height
1,000mm
Depth
223mm
Width
800mm
Flow rate
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 9 lpm
Thickness
Glass mirror: 4mm
Finish
304 stainless steel with a matte black melamine finish
Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
Suitable for flush horizontal under-counter mounting.
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
With deep-drawn paper removal opening for easy paper removal.
Designed for approx. 500 standard paper towels in zigzag- or c-fold. Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through lockable drawer.
Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
Wear parts can be replaced as modules.
Installation dimensions: 300 x 150 mm
Mounting: With screws on the inside.
Delivery includes fixing material and one pack of paper towels.
Weight (in kg): 5,6
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
727408
highly polished
731408
(coloured) plastic powder - coating
728128
Suggested text for specifications:
Paper towel dispenser in stainless steel (AISI 304) for flush horizontal under-counter mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. With deep-drawn paper removal opening, filling quantity approx. 500 paper towels. Accessible for refilling through lockable drawer. Keyed alike cylinder lock in corrosion-resistant zinc die-casting. Delivery includes fixing material and one pack of paper towels.
