SLP 37RZ

Urinal Vila with cover, with a radar flushing unit and with integrated power supply, 230 V AC

Characteristics

economy flushing by 1 liter of water
easy installation
whole flushing unit is placed behind the urinal
system reacts only on the direct use of the urinal (it analyses changes, which are proceeded inside of the urinal, when a liquid is flowing through)
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 04 without the necessity to dismantle the urinal from the wall (acoustic setting indication)
automatic flushing after each 6 hours non-use
water flow could be regulated by ball valve
radar flushing unit recharges a water to the siphon after each flushing

Order number	01375
Code	SLP 37RZ

Supply specification

SLP 37RZ - Supply No. 01375 - ceramic urinal with the radar flushing unit, plastic mounting box with brass screw coupling, electromagnetic valve and ball valve, inlet fitting with a rubber sealing, siphon, mounting set, plastic cover, power supply

Technical information

Mounting box dimension: 140 x 140 x 75 mm
Operating voltage: 230 V AC/50 Hz
Recommended flow pressure: 0,1 - 0,6 MPa
Rate of flow: 18 l/min (inf.data)
Water inlet: male thread G 3/4“
Water outlet: inlet fitting with a rubber sealing

994,65 € (-5%) 1047,00 €

Tool WEB 950 plastikust punane koos käepidemega

Tootekood: WEB950RED , Tarneaeg: 7-14 päeva

Tool WEB950 koos käepidemega

96,00 € (-20%) 120,00 €

Kätekuivati BJÖRK must/BIRCH plaadiga

Tootekood: DAN3006-76 , Tarneaeg: 14-21 päev

PRODUCT DESCRIPTION

• Winner of a Red Dot Design Award!

• Drying cycle of only 10-15 seconds.

• Powerful commutator motor with carbon brushes.

• Comes in trendy matt black and classic white as standard.

• Also available in all RAL colours and coated with different prints.

• Top plate in 6 optional standard designs.

• LED light indicates when machine is in use.

• Adjustable sensor range, motor speed and heating setting.

• 5-year warranty.

SPECIFICATIONS
Product number:	3006 / EAN no. 5-709818-030067
Technical data:	Touch-free hand dryer with matt black steel housing (RAL 9005, gloss 3). Equipped with top plate. Infra-red sensor and elektronic timer. Drying cycle: 10-15 sec. IPX1, 230 V, 50/60 Hz, 1600 W, Class I (earthed). 76 dBA.
Dimensions	H: 330 mm, W: 205 mm, D: 183 mm
Net Weight:	6.5 kg
