Horisontaalne nurga käetugi, 3-punkti kinnitus. Toru d 32 mm.
• 90º wall to wall horizontal grab bar for showers, baths and changing rooms, with three anchoring points and with snap flange covers, made with stainless steel tube, folded in an "L" shape at 90º.
• Designed to achieve barrier-free accessibility in bathrooms and public spaces. This grab bar is suitable for specific spaces for the elderly or people with reduced mobility. Model suitable for collectivities.
• Stainless steel gives this bar great durability and great resistance to rust.
• The bar has three snap flange covers that conceal the anchoring screws to the wall and reinforce, even more, the beauty of the product once installed.
• Optionally, these bars can be electrically isolated by installing the Electrical Isolation Kit code KA0020.
• Supplied with all the necessary hardware to fix the bar to a brick wall.
General description
Mediepoxi / Medinox series
BD0700C BD0700CS Bright finish Satin finish
90o wall to wall horizontal grab bar for showers, baths and changing rooms, with three anchoring points and with snap flange covers, made with stainless steel tube, folded in an "L" shape at 90o.
Designed to achieve barrier-free accessibility in bathrooms and public spaces. This grab bar is suitable for specific spaces for the elderly or people with reduced mobility. Model suitable for collectivities.
Stainless steel gives this bar great durability and great resistance to rust.
The bar has three snap flange covers that conceal the anchoring screws to the wall and reinforce, even more, the beauty of the product once
installed.
Optionally, these bars can be electrically isolated by installing the Electrical Isolation Kit code KA0020.
Supplied with all the necessary hardware to fix the bar to a brick wall.
Components and materials
BD2700: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 201 stainless steel tube white finish.
BD2700B: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 201 stainless steel tube matte black finish.
BD0700C: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 304 stainless steel tube bright finish.
BD0700CS: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 304 stainless steel tube satin finish.
TUBING: made of stainless steel 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the
diameter along the bends.
CONCEALED WALL BRACKET: three units made of stainless steel sheet, 3 mm thick and joined to the bar by welding to the ends of the
tube. It has three holes (BD2700 and BD2700B) or two holes (other references), with a diameter of 6.5 mm that allow the fixing of the bar
to the wall.
SNAP FLANGE COVER: three units that conceal the installation screws made of 1.5 mm thick polypropylene (BD2700 and BD2700B) or
COMBINATION PAPER TOWEL- AND FOAM SOAP DISPENSER AND WASTE BIN WP 500-5
298 x 1348 x 120 mm ca. 250 paper towels / 400 ml foam soap concentrate / 11 l
Combination consisting of a foam soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Foam soap dispenser with one-hand operated and non-drip foam soap pump.
Designed for standard 400 ml foam soap concentrate.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
Inspection slots to indicate fill level.
Accessible for refilling through lockable front flap with fall protection.
Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 300 x 1350 x 110 mm
Mounting: With eight screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material, first fill with soap and one pack of paper towels.
