BROEN LAB Segistid, laborikraanid, ventiilid -labori
S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg
MATERIALS WITH MEDIA CONTACT
Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
Broen Lab Kraan deioniseeritud vesi S200mm, seinast PVDF
S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-65°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg
MATERIALS WITH MEDIA CONTACT
Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
Broen vee voolik, PEX 1000mm, Uni Flex-1/2" H2O
Keraamiline tööorgan veekraanile BROEN-LAB UniFlex
ref.1976000
METALLKÄEPIDE
S P E C I F I K AT S I O O N I D
BROEN-LAB UniFlex™ metallist veesegistid metallkäepidemetega on varustatud keraamiliste 180° pöördega peaosadega.
Keraamiliste peaosadega segistid võimaldavad kiiret ja täpset reguleerimist ning pikaajalist töökindlust.
Avamise/sulgemise funktsioon: 1 x 180° pööre
Kasutusala: Kuum/külm vesi
Temperatuurivahemik: Maksimaalselt 90°C
Maksimaalne töörõhk: 10 bar / 147 psi
Testirõhk: 1 x töörõhk
MATERJALID, MIS PUUTUVAD KOKKU MEEDIASTA
- Metallid: Messing
- Tihendid: EPDM
- Plastik: POM
- Määrdeaine: Silikoonil põhinev
- Keraamika: 96% alumiiniumoksiid
METAL HANDLE
S P E C I F I C AT I O N S
BROEN-LAB UniFlexTM Metal water fittings with metal handles are delivered with ceramic 180° turn headworks.
Water fittings with ceramic headwork offer quick and precise adjustment and a long service life.
Opening/closing function: 1 x 180° turn Media: Hot/cold water
Temperature range: Maximum 90°C Max. working pressure: 10 bar / 147 psi Test pressure: 1 x working pressure
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Sealing: EPDM
Plastics: POM
Lubricant: Silicone based Ceramics: Al-oxyd 96%
S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg
MATERIALS WITH MEDIA CONTACT
Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg
MATERIALS WITH MEDIA CONTACT
Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg
MATERIALS WITH MEDIA CONTACT
Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
Laborikraan Broen-Lab Sensoriga tööpinnale. S=200mm.220V
Pöördepiiraja 110 kraadi. Valge (RAL0008500)
Broen-LAB
Specifications
Aerator, with flow limitation 5 L/min
Sensor operated opening and closing function with bi-stabile technology
110° limited swivel spout
Temperatur range: 5-65° (41°F - 149°F) Max. working pressure: 10 bar/145 psi
Surface
Chemical resistant Polyester Based Surface treatment, UV-resistent.
BROEN-LAB colour: 2700 (RAL colour: 0008500)
Material with media contact
Brass
Rubber, EPDM
Silicone based lubricant PPSU
SS
PA
SPX Hose
Electrical connection
Adaptor: 100-240 V AC 50/60 Hz Battery: 6 V Lithium
Hose
Supplied with hoses.
Hose (1) on the picture is mandatory and included. Hose (2) on the picture is optional. See in the table below which options you have for hose (2)*.
For further options contact BROEN-LAB
Laborisegisti Broen-Lab Sensorsegisti tööpinnale. S=200mm.220V
Pöördepiiraja 110 kraadi. Valge (RAL0008500)
Temp.regulaator FCP sensoriga jooksutorule.
Paindühendused 700mm,G1/2" mutter
Broen-LAB
Sensor Tap with temperature adjustor M30x1.5 mm mounting
Specifications
Aerator, with flow limitation 5 L/min
Sensor operated opening and closing function with bi-stabile technology
110° limited swivel spout
Non-return valve integrated in valvehouse
Temperatur range: 5-65° (41°F - 149°F)
Max. working pressure: 10 bar/145 psi
Surface
Chemical resistant Polyester Based Surface treatment, UV-resistent.
BROEN-LAB colour: 2700 (RAL colour: 0008500)
Material with media contact
Brass
Rubber, EPDM
Silicone based lubricant PPSU
SS
PA
SPX Hose
Electrical connection
Adaptor: 100-240 V AC 50/60 Hz Battery: 6 V Lithium
Hose
Supplied with hoses.
Hose (1) and (2) on the picture are mandatory and included. The hoses (3) on the picture are optional. See in the table below which options you have for the hoses (3)*.
For further options contact BROEN-LAB
Single valve turret fitting for compressed air with quick release coupling
1-Valve,Turret,1-Hole,Quick Coup.,M30,Hose,CA
2532 056 1021-52B
compressed air, nitrogen, carbon dioxide, argon, helium, low vacuum (1000 to 1 mbar)
Fittings are delivered with a 700mm SPX hose with OD10mm inlet conneciton.
MATERIALS WITH MEDIA CONTACT
Metals: Brass
Plastics: PVDF, SPX (hose)
Sealing: FKM
Lubricant: Perfluoropolyether based
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
Other options:
- different media
- removable hose nozzle with union nut
- disability-friendly handle (single valve only)
- micro flow headwork (for 2.0 non-burning gases) - high flow headwork (for 2.0 non-burning gases)
- alternative hose inlet connection / without a hose - other inlet options (type, length)
Vaakumpuump tagasilöögiklapiga 1/2"
Boss 19198009 Lab.Armatur DN15
