BROEN LAB Segistid, kraanid, ventiilid -labori

Broen Lab Kraan deioniseeritud vesi S150mm, recirkulatsioon d25mm WDC

BROEN-LAB fully recirculating fittings ensure constant fresh

water with no dead legs even when the point-of-use valve is in closed position.

The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.

SPECIFICATIONS

Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792

Hose nozzle: Removable plastic

Headwork: Diaphragm type

Opening/closing function: 1 1/2 x 360°

Temperature range: 0-65°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.8 kg

MATERIALS WITH MEDIA CONTACT

Diaphragm: PTFE

Plastics: PP, PP-n, PVDF

Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- also available in ABS (1, 11/4 , 11/2)

Tootekood: B-25330431036 , Tarneaeg: 14-21 päeva

410,00 €

Broen Lab Kraan deioniseeritud vesi S150mm, seinast WDC

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Tootekood: B-25330011036 , Tarneaeg: 14-21 päeva

253,00 €

Broen LAB Labori segisti kangiga käsiduššiga H-300mm S-150mm

S P E C I F I CATIONS

Handle: Metal, BROEN POLYCOAT powder coated

Spout: Swivel action

Hose nozzle: Aerator

Cartridge: Ceramic (temperature and flow regulation type)

Opening/closing function: 25°, mixing function: ±45°

Temperature range: 0°C - 90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 2.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- removable hose nozzle

MOUNTING INFORMATION

Tootekood: B-25350421035-52C , Tarneaeg: 2-4 nädalad

494,00 € (5%)
520,00 €

Broen LAB Labori segisti kangiga käsiduššiga H-300mm S-200mm

S P E C I F I CATIONS

Handle: Metal, BROEN POLYCOAT powder coated

Spout: Swivel action

Hose nozzle: Aerator

Cartridge: Ceramic (temperature and flow regulation type)

Opening/closing function: 25°, mixing function: ±45°

Temperature range: 0°C - 90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 2.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- removable hose nozzle

MOUNTING INFORMATION

Tootekood: B-25350431035-52C , Tarneaeg: 2-4 nädalad

525,00 €

Broen LAB Labori segisti kangiga käsiduššiga H-300mm S-250mm

S P E C I F I CATIONS

Handle: Metal, BROEN POLYCOAT powder coated

Spout: Swivel action

Hose nozzle: Aerator

Cartridge: Ceramic (temperature and flow regulation type)

Opening/closing function: 25°, mixing function: ±45°

Temperature range: 0°C - 90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 2.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- removable hose nozzle

MOUNTING INFORMATION

Tootekood: B-25350441035-52C , Tarneaeg: 2-4 nädalad

531,00 €

Broen LAB Labori segisti kangiga käsiduššiga H-300mm S-300mm

S P E C I F I CATIONS

Handle: Metal, BROEN POLYCOAT powder coated

Spout: Swivel action

Hose nozzle: Aerator

Cartridge: Ceramic (temperature and flow regulation type)

Opening/closing function: 25°, mixing function: ±45°

Temperature range: 0°C - 90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 2.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- removable hose nozzle

MOUNTING INFORMATION

Tootekood: B-25350451035-52C , Tarneaeg: 2-4 nädalad

541,00 €

Kraan deioniseeritud vesi S200mm, seinast WDC

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Tootekood: B-25330021036 , Tarneaeg: 14-21 päeva

265,00 €

Kraan destilleeritud vesi S150mm, recirkulatsioon d25mm WDI

BROEN-LAB fully recirculating fittings ensure constant fresh

water with no dead legs even when the point-of-use valve is in closed position.

The Tee-piece of the fitting should be connected to a loop with a constant circulation of water. For more details about installation, jointing methods, etc. please refer to page 22.

SPECIFICATIONS

Handle: Metal, BROEN-LAB POLYCOAT powder coated

with media indication according to EN13792

Hose nozzle: Removable plastic

Headwork: Diaphragm type

Opening/closing function: 1 1/2 x 360°

Temperature range: 0-65°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.8 kg

MATERIALS WITH MEDIA CONTACT

Diaphragm: PTFE

Plastics: PP, PP-n, PVDF

Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- also available in ABS (1, 11/4 , 11/2)

Tootekood: B-25330431003 , Tarneaeg: 14-21 päeva

409,00 €

Kraan destilleeritud vesi S150mm, seinast WDI

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Tootekood: B-25330011003 , Tarneaeg: 14-21 päeva

255,00 €

Kraan destilleeritud vesi S200mm, seinast WDI

S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated

MATERIALS WITH MEDIA CONTACT

Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Tootekood: B-25330021003 , Tarneaeg: 14-21 päeva

265,00 €

Külma või eelsegatud vee kraan F-150MM Broen Lab

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Tootekood: B-25340011001-52B , Tarneaeg: 3-7 päeva

172,80 € (10%)
192,00 €

Külma või eelsegatud vee kraan F-200MM Broen Lab

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Tootekood: B-25340021001-52B , Tarneaeg: 3-7 päeva

172,80 € (10%)
192,00 €

Külma või eelsegatud vee kraan F-300MM

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Tootekood: B-25340161001-52B , Tarneaeg: 3-7 päeva

198,00 €

LAB segisti , F-150mm, WPH/WPC (15281009) Broen Lab

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 3 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

Solder: DIN L-Ag55:Sn

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

Tootekood: B-25360011039-52B , Tarneaeg: 3-4 päeva

255,60 € (10%)
284,00 €

LAB segisti , F-200mm, WPH/WPC (15281009) Broen Lab

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 3 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

Solder: DIN L-Ag55:Sn

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

Tootekood: B25360021039-52B , Tarneaeg: 3-4 päeva

258,30 € (10%)
287,00 €

LAB segisti , F-250mm, WPH/WPC (152823009) Broen Lab

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 3 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

Solder: DIN L-Ag55:Sn

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

Tootekood: B-25360131039-52B , Tarneaeg: 3-4 päeva

294,00 €

Labori sensoriga kraan külmale veele tööpinnale. S=200mm.220V

Laborikraan Broen-Lab Sensoriga tööpinnale. S=200mm.220V

Pöördepiiraja 110 kraadi. Valge (RAL0008500)

Broen-LAB

Specifications

Aerator, with flow limitation 5 L/min
Sensor operated opening and closing function with bi-stabile technology
110° limited swivel spout

Temperatur range: 5-65° (41°F - 149°F) Max. working pressure: 10 bar/145 psi

Surface

Chemical resistant Polyester Based Surface treatment, UV-resistent.
BROEN-LAB colour: 2700 (RAL colour: 0008500)

Material with media contact

Brass
Rubber, EPDM
Silicone based lubricant PPSU
SS
PA
SPX Hose

Electrical connection

Adaptor: 100-240 V AC 50/60 Hz Battery: 6 V Lithium

Hose

Supplied with hoses.
Hose (1) on the picture is mandatory and included. Hose (2) on the picture is optional. See in the table below which options you have for hose (2)*.
For further options contact BROEN-LAB

Tootekood: B-26010171035-52 , Tarneaeg: 14-21 päeva

739,00 €

Labori sensoriga segisti tööpinnale. S=200mm.220V+Temp.regulaator FCP sensoriga jooksutorule

Laborisegisti Broen-Lab Sensorsegisti tööpinnale. S=200mm.220V

Pöördepiiraja 110 kraadi. Valge (RAL0008500)

Temp.regulaator FCP sensoriga jooksutorule.

Paindühendused 700mm,G1/2" mutter

Broen-LAB

Sensor Tap with temperature adjustor M30x1.5 mm mounting

Specifications

Aerator, with flow limitation 5 L/min
Sensor operated opening and closing function with bi-stabile technology
110° limited swivel spout
Non-return valve integrated in valvehouse
Temperatur range: 5-65° (41°F - 149°F)
Max. working pressure: 10 bar/145 psi

Surface

Chemical resistant Polyester Based Surface treatment, UV-resistent.
BROEN-LAB colour: 2700 (RAL colour: 0008500)

Material with media contact

Brass
Rubber, EPDM
Silicone based lubricant PPSU
SS
PA
SPX Hose

Electrical connection

Adaptor: 100-240 V AC 50/60 Hz Battery: 6 V Lithium

Hose

Supplied with hoses.
Hose (1) and (2) on the picture are mandatory and included. The hoses (3) on the picture are optional. See in the table below which options you have for the hoses (3)*.

For further options contact BROEN-LAB

Tootekood: B-26010171035-52+B-26020021035E , Tarneaeg: 14-21 päeva

1043,00 €
