Vieser Dot põranda trapi süsteem

Vieser Dot põranda trapi süsteem

Vieser Dot põranda trapi süsteem

Vieser Dot floor drain system

Järjesta:
Kuva: Nimekirjana / Võrgustikuna





Vieser 6001178 DOT ⌀600mm - Tray renn ümmargune RST


Roostevaba teras


Vieser Dot ⌀600mm - Tray

HVAC No. 3315981


The Vieser Dot floor drain system consists of two separate parts: a tray and the chosen cover. In addition, the Vieser floor drain that is right for the floor drain system is sold separately.

Vieser Dot, with its innovative shape and size, represents a new kind of floor drain system that adds the finishing touch to your bathroom’s interior.

  • Compatibility with all Vieser One floor drains means that you can choose either a vertical, horizontal or untrapped floor drain, thereby also guaranteeing quick and easy installation.
  • With Vieser One drains, you can also make use of three DN32/40 side inlets for the floor drain to facilitate the placement of the drain and the installation of the pipeline.
  • Suitable for both new construction and renovations.
  • The watertightness and proper functioning of the floor drain have been proven in rigorous tests conducted according to the standard EN 1253-2, on which the Vieser One floor drain type approvals are also based. (Vieser One floor drain type approval)
  • The Vieser Dot floor drain system has a patented solution that enables entirely safe installation and a completely watertight membrane joint. The compatibility and watertightness of Vieser One floor drains and the liquid-applied waterproofing of wet spaces have been proven in tests conducted according to the standard EN 1253-1, on which Vieser’s product certificates are also based. (Vieser One and Vieser product certificate) & (Vieser One and Vieser product certificate when using the Vieser membrane flange)
  • Vieser Dot is a very user-friendly floor drain system. Compatibility with Vieser One floor drains offers the user an easy-to-remove water trap that is easy to clean and reinstall.

Vieser’s drain and cover combination comes with a 10-year system guarantee.

Tootekood: AKV6001178 ,   Tarneaeg: 3-7 päeva
866,20 €

Vieser 6001186 DOT Kenoby, õlitatud D600MM ümmargune

Vieser Dot Kebony Cover, Oiled

HVAC No. 3315993
EAN 6430066741625


One cover option offered for the Vieser Dot Design floor drain system is Vieser Dot ⌀600mm Kebony, Oiled. Kebony is wood that has been treated using natural methods. Although the treatments provide the covers with a natural protection, we recommend treating the wooden covers with a protective agent once or twice a year.

The Vieser Dot floor drain system consists of two separate parts: a tray and the chosen cover. In addition, the Vieser floor drain that is right for the floor drain system is sold separately:



Non-toxic and ecologically produced Kebony is hard, durable and beautiful wood. Kebony® products are based on a patented process that involves impregnating the wood with furfuryl alcohol using high pressure and heat, thereby altering the wood’s molecular structure. The 100% bio-based liquid treatment, primarily based on furfuryl alcohol, is a byproduct of sugar cane production. This makes the wood non-toxic and thus completely safe. Kebony has been granted the Nordic Swan Ecolabel. Kebony is sustainably sourced: 100% radiata pine, sourced from forests that have been granted FSC, PEFC or other regional certification.

Vieser’s drain and cover combination comes with a 10-year system guarantee.




Tootekood: AKV6001186 ,   Tarneaeg: 3-7 päeva
1134,60 €

Vieser 6001188 DOT Accoya õlitatud D600MM ümmargune



Vieser Dot Cover Accoya, Oiled

HVAC No. 3315995
EAN 6430066741649

One cover option offered for the Vieser Dot Design floor drain system is Vieser Dot ⌀600mm Accoya, Oiled. Accoya is wood that has been treated using natural methods. Although the treatments provide the covers with a natural protection, we recommend treating the wooden covers with a protective agent once or twice a year.

The Vieser Dot floor drain system consists of two separate parts: a tray and the chosen cover. In addition, the Vieser floor drain that is right for the floor drain system is sold separately:



Accoya wood, produced under the Accoya trademark, is acetylated radiata pine. Acetylation refers to a process in which wood is treated with acetic anhydride. Accoya is naturally renewable, and it is also more durable than many threatened tropical hardwoods. Accoya has been granted numerous environmental certificates, including the Nordic Swan Ecolabel. All Accoya® wood is procured from well-managed forests that meet environmental requirements and which have been granted FSC, PEFC or other regional certification.

Vieser’s drain and cover combination comes with a 10-year system guarantee.

Technical specifications

Vieser No.
6001188
HVAC No.
3315995
EAN
6430066741649
Package (box/pallet)
1/10
Package dimensions
66 x 4,5 x 66cm
Package weight
12,5kg
Material
Accoya, Oiled
The size of the wooden lath in the floor drain cover
32,72mm
The size of the openings in the floor drain cover
4mm
General information

The package contains: The Vieser Dot ⌀600 mm Accoya cover and the Vieser lifting tool to make cleaning the drain easier.

The Vieser Dot floor drain system consists of two separate parts: a tray and the chosen cover. In addition, the Vieser floor drain that is right for the floor drain system is sold separately:



Tootekood: AKV6001188 ,   Tarneaeg: 3-7 päeva
1134,60 €

Vieser 6001190 DOT Accoya vahatatud D600MM ümmargune

Vieser Dot Cover Accoya, Waxed

HVAC No. 3315997
EAN 6430066741663

One cover option offered for the Vieser Dot Design floor drain system is Vieser Dot ⌀600mm Accoya, Waxed. Accoya is wood that has been treated using natural methods. Although the treatments provide the covers with a natural protection, we recommend treating the wooden covers with a protective agent once or twice a year.

The Vieser Dot floor drain system consists of two separate parts: a tray and the chosen cover. In addition, the Vieser floor drain that is right for the floor drain system is sold separately:



Accoya wood, produced under the Accoya trademark, is acetylated radiata pine. Acetylation refers to a process in which wood is treated with acetic anhydride. Accoya is naturally renewable, and it is also more durable than many threatened tropical hardwoods. Accoya has been granted numerous environmental certificates, including the Nordic Swan Ecolabel. All Accoya® wood is procured from well-managed forests that meet environmental requirements and which have been granted FSC, PEFC or other regional certification.

Vieser’s drain and cover combination comes with a 10-year system guarantee.

Technical specifications

Vieser No.
6001190
HVAC No.
3315997
EAN
6430066741663
Package (box/pallet)
1/10
Package dimensions
66 x 4,5 x 66cm
Package weight
12,5kg
Material
Accoya, Waxed
The size of the wooden lath in the floor drain cover:
32,72mm
The size of the openings in the floor drain cover
4mm
General information

The package contains: The Vieser Dot ⌀600 mm Accoya cover and the Vieser lifting tool to make cleaning the drain easier.

The Vieser Dot floor drain system consists of two separate parts: a tray and the chosen cover. In addition, the Vieser floor drain that is right for the floor drain system is sold separately:



Tootekood: AKV6001190 ,   Tarneaeg: 3-7 päeva
1134,60 €
