General Description

•   Liquid soap dispenser of 1.5 L capacity, manufactured in stainless steel AISI 304, 0,8 mm thick, to be installed directly on the wall and lever-operated by means of an stainless steel lever.

•   Available in four finishes (white, black, bright and satin) these soap dispenser models have a functional, robust and trendy design that matches the new range of Mediclinics bathroom accessories. This allows this soap dispenser to blend into any space perfectly.

•   Suitable for high traffic facilities and for public use.

•   Dispenses liquid soaps or hydro-alcoholic gel. Surgical soaps and soaps with solid abrasive particles are not supported.

  Components & materials

  •   DJP0034: Stainless steel AISI 304, white epoxy finish.

  •   DJP0034C: Stainless steel AISI 304, bright finish.

  •   DJP0034CS: Stainless steel AISI 304, satin finish.

  •   DJP0034B: Stainless steel AISI 304, black epoxy finish.

  •   Level display in the front part that constantly indicates the level of soap available inside the soap dispenser.

  •   Inner plastic tank that prevents oxidation and that can be easily removed for cleaning and disinfection purposes.

  •   Lever made in stainless steel.

  •   Anti-drip corrosion resistant valve that dispenses 1.5 ml of soap per service. This anti-drip valve, which dispenses liquid soap, is easily interchangeable with the valves of the other soap dispensers of the same line.

  •   Hinged cover for operator convenience and speed of service.

  •   Opening on top with provided Mediclinics key that allows soap refill.

  •   It is mounted on the wall by means of four Ø4 stainless steel screws (provided) with their corresponding Ø 6mm plastic plugs (also provided).

  •   It is recommended to use liquid soaps or disinfectant gel soaps (maximum of alcohol content of 85 %) with a density between 0.9 and 1.35 kg/dm3 and a maximum viscosity of 3,000 cps.

General description

•   Wall to wall grab bar with three support points, made of diameter 32 mm AISI 304 stainless steel tube, to be installed in the washbasins and toilets.

•   With snap flange covers to conceal the screws, helping to achieve a beautiful and sleek look and protecting the flange surfaces from damage, dust, moisture and foreign particles.

•   Ideal to design barrier-free accessibility, both domestic and commercial places, these grab bars help make the lives easier for the handicapped and elderly people.

•   Highest durability and rusting resistance.

•   Optionally, these bars can be electrically isolated by installing the electrical isolation Kit code KA0020.

•   These grab bars are supplied with a kit to fix the bar to a brick wall.

  Components and materials

•   BFD600C: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, bright finish.

•   BFI600C: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, bright finish.

•   BFD600CS: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, satin finish.

•   BFI600CS: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, satin finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along the bends.

•   CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes for wall mounting.

•   SNAP FLANGE COVER: three units made of stainless steel AISI 304, 0.8 mm thick and Ø 82 mm. Each cover snaps over mounting flange to conceal mounting screws.
