Broen Lab PP labori valamu 552x400x235 (PxLxK)

Pudelisifoon labori valamule 1 1/2"

SPECIFICATIONS

Temperature range: 0-80°C

Standard colour: black (other colours available on request )

Net weight: 0.5 kg

Dimensions: IN: 1½” BSP

OUT: 40mm (metric)

Height adjustable: telescopic bottle trap

Injection moulded from polypropylene copolymer resin, this anti-siphon bottle trap come with inlet of 1½” BSP, with black bowl.

PP BOTTLE TRAP

PRODUCT NUMBER 97B0040

PRODUCT NUMBER 97B0023

SPECIFICATIONS

Temperature range: 0-80°C

Standard colour: black (other colours available on request )

Net weight: 0.5 kg

Dimensions: IN: 1½” BSP

OUT: 40mm (metric)

Injection moulded

Tootekood: B-97B0040 (97B0080) , Tarneaeg: 2-3 nädalad

36,90 € (10%)
41,00 €

Valamu äravool labori valamule 1 1/2" BSP x 70mm

SPECIFICATIONS

Temperature range: 0-80°C

Standard colour: black

Net weight: 0.2 kg

Dimensions: Ø73, 1½” BSP (tolerance ± 1mm)

Including adjustable screw on nutø

Tootekood: B-97B0073 , Tarneaeg: 7-14 päeva

16,20 € (10%)
18,00 €

Sarnased tooted

SOS dušš, seinale kinnituv 1/2"

Tootekood: BR-17082009 , Tarneaeg: 7 päeva

378,00 € (10%)
420,00 €

Külma või eelsegatud vee kraan F-150MM Broen Lab

S P E C I F I CATIONS

The fitting is delivered with an integrated BALLOFIX® ball valve.

Handle: Metal, BROEN POLYCOAT powder coated

with media indication according to EN13792

Spout: Full swivel action

Hose nozzle: Removable metal

Headwork: Ceramic

Opening/closing function: 180° (wrist action lever: 90°)

Temperature range: 0-90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 1.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- aerator

- fixed hose nozzle

- integrated non-return valve

- fixed spout

- alternative hose inlet connection / without a hose

- other inlet options (type, length)

- national approvals

- WPH (Water Potable Hot)

- WNH (Water Non-Potable Hot)

Tootekood: B-25340011001-52B , Tarneaeg: 3-7 päeva

178,20 € (10%)
198,00 €

Silmadush Broen , seinakinnitusega

8 l/min

Tootekood: B-17713000 , Tarneaeg: 7-14 päeva

356,40 € (10%)
396,00 €

Broen LAB Labori segisti kangiga käsiduššiga H-300mm S-300mm

S P E C I F I CATIONS

Handle: Metal, BROEN POLYCOAT powder coated

Spout: Swivel action

Hose nozzle: Aerator

Cartridge: Ceramic (temperature and flow regulation type)

Opening/closing function: 25°, mixing function: ±45°

Temperature range: 0°C - 90°C

Max. working pressure: 10 bar / 147 psi

Test pressure: 1 x working pressure

Weight: 2.4 kg

MATERIALS WITH MEDIA CONTACT

Metals: Brass

Plastics: POM, PTFE, SPX (hose)

Sealing: EPDM

Lubricant: Silicone based

Ceramics: Al2O3 96%

ORDERING INFORMATION

For standard configuration please refer to the item

numbers below.

Other options:

- removable hose nozzle

MOUNTING INFORMATION

Tootekood: B-25350451035-52C , Tarneaeg: 2-4 nädalad

582,00 €

Ühe ventiiliga toruliitmik suruõhu jaoks ,Turret,1-Hole,Quick Coup.,M30,Hose,CA

Single valve turret fitting for compressed air with quick release coupling

1-Valve,Turret,1-Hole,Quick Coup.,M30,Hose,CA

2532 056 1021-52B

compressed air, nitrogen, carbon dioxide, argon, helium, low vacuum (1000 to 1 mbar)

Fittings are delivered with a 700mm SPX hose with OD10mm inlet conneciton.

MATERIALS WITH MEDIA CONTACT

Metals: Brass
Plastics: PVDF, SPX (hose)
Sealing: FKM
Lubricant: Perfluoropolyether based

ORDERING INFORMATION

For standard configuration please refer to the item numbers below.

Other options:
- different media
- removable hose nozzle with union nut
- disability-friendly handle (single valve only)
- micro flow headwork (for 2.0 non-burning gases) - high flow headwork (for 2.0 non-burning gases)
- alternative hose inlet connection / without a hose - other inlet options (type, length)

Tootekood: BR-25320561021-52B , Tarneaeg: 14-21 päeva

225,00 €
