Ø 45 x 170 x 155 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

Roostevaba teras

harjatud

Tootja FROST, Taani

kõrgus 48mm

pikkus 200mm

sügavus 120mm

kaal 1 kg

Ø 45 x 233 x 107 mm

• Double reserve toilet roll holder, right angled, in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Designed for up to two standard toilet rolls with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 20 mm, length 233 mm.
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,70
