Seebidosaator

poleeritud, R/V teras AISI304

Maht 1L

Seebidosaator

harjatud, R/V teras AISI304

Maht 0,2L

70x172x90mm

DIMENSIONS
Width: 660 mm, Height: 780 mm, Depth closed: 200 mm, Depth open: 770 mm

Rootsi

Puidust

Valge+puu

Seebidosaatori eModule (ilma patareideta, Wagner Ewar)

Infrapunaanduriga moodulit saab kasutada mitmes EWAR® seebidosaatoris ja kombinatsioonides seebidosaatoritega.
Alternatiivselt võib kasutada kaubanduslikult saadaval olevaid 500 ml või 950 ml seebipudeleid või 200 ml mahutit.
Tööpingepinge: 3V (2 LR14 patareid), kuni 3000 aktiveerimist.
Patareipesa asub paremal ja on hõlpsasti ligipääsetav ilma seebimahutit eemaldamata.
3V vooluadapter patareideta kasutamiseks on saadaval lisatarvikuna.
Andurimoodul ja pump on modulaarse kujundusega ning neid saab tööriistadeta vahetada.
Hooldusrežiim: andurimoodul lülitub välja, kui seadme korpus avatakse.
Hoiatusnäidik madala patarei taseme kohta.
Tuvastusvahemik: umbes 5 cm (mõõdetakse automaatselt).
Andur tuvastab valguse muutusi (kaitseb väärkasutuse eest, näiteks anduripinna katmisega).
Kaal: 0,22 kg.

• PP101e-7
• PP102e-1
• PP102e-7
• PP102e-7S
• WP101e
• WP101e-7
• WP102e
• WP102e-1
• WP102e-7
• WP102e-7S
• WP102e-7T
• WP173e
• WP173e-1
• WP173e-7
• WP174e
• WP174e-2
• WP174e-7
• WP208e
• WP208e-7
• WP500e
• WP510e
• WP550e
• WP575e
• WP585e
• WP585e-7
• WP600e
• WP650e

• Infra-red sensor module can be used in several EWAR® soap dispensers and combinations with soap dispensers.
• Alternatively, can be operated with commercially available 500 ml or 950 ml soap bottles or with 200 ml tank.
• Operating voltage 3V, (2 LR14 baby batteries), for up to 3000 actuations.
• Battery compartment on the right is easily accessible without removing the soap tank.
• 3V mains supply for batteryless operation available as an accessory.
• Sensor module and pump in modular design and can be replaced without tools.
• Service mode: sensor module switches off when device housing is opened.
• Warning display for low battery level.
• Detection range approx. 5 cm (is measured automatically).
• Sensor detects light changes (protects against misuse e.g. by masking the sensor surface).
• Weight: 0,22 kg

298 x 898 x 120 mm
ca. 250 paper towels / 11 l

• Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 900 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 9,3
