Delabie köögisegisti Professionaalne köök 6693
Kaubamärk:
Ühik: tk
Tarneaeg: 14-21 päeva
Lisainfo: info@pegu.ee
SUVI261 sisesta sooduskood ostukorvi lehel kupongi lahtrisse!
Pre-rinse set with mixer
Ref. 6693
Complete pre-rinse set without bib tap.
Deck-mounted single hole mixer with slimline control lever.
Supplied with F3/8" flexibles and non-return valves.
White, scale-resistant M1/2" hand spray with adjustable jet and 9 lpm flow rate at the outlet.
Reinforced, food-grade, white flexible hose L. 0.95m.
3/4" brass column.
Adjustable wall bracket.
Stainless steel spring guide.
TECHNICAL FEATURES
Pre-rinse set with mixer
Ref. 6693
| Connector | F3/8" |
|---|---|
| Height | 1105-1225 mm |
| Drop height | 340-580 mm |
| Flow rate | 9 lpm |
| Width to the wall | 35-162 mm |
| Finish | Chrome-plated brass |
Failid
Wall-mounted pre-rinse set with mixer
Ref. 5634
Complete pre-rinse set with bib tap.
Wall-mounted mixer, F3/4" with adjustable centres with:
- Valve heads with reinforced mechanisms with ergonomic control levers.
- M1/2" M3/4" offset connectors.
- Non-return valves integrated in the mixer.
Bib tap with:
- Swivelling, tubular spout L. 200mm.
- 25 lpm full flow rate achieved within 90°.
- Valve head with reinforced mechanism with ergonomic control lever.
Black, scale-resistant M1/2" hand spray with adjustable jet and 9 lpm flow rate at the outlet.
Black, reinforced, food-grade flexible hose L.0.95m.
3/4" brass column.
Adjustable wall bracket.
Stainless steel spring guide.
TECHNICAL FEATURES
Wall-mounted pre-rinse set with mixer
Ref. 5634
| Connector | M1/2" |
|---|---|
| Height | 860 - 930mm |
| Flow rate | 25 lpm |
| Width to the wall | 35 - 162mm |
| Finish | Chrome-plated brass |
Pressure-balancing mixer set and column with retracting hand spray
Ref. 2599EP
Ideal for babies' baths.
Anti-scalding safety: HW flow rate is reduced if CW supply fails.
Securitouch thermal insulation prevents burns.
Retracting hand spray with 2 jet options: flow straightener/rain effect.
Swivelling column H. 200mm L. 220mm.
Retracting hand spray with two jet options (flow straightener/rain effect)
Ø 35mm pressure-balancing ceramic cartridge with pre-set maximum temperature limiter.
Mixer body and column with smooth interiors.
Flow rate 12 lpm at 3 bar.
Sculptured control lever.
Mixed water outlet L. 160mm.
BIOSAFE flexible shower hose reduces bacterial proliferation: transparent polyurethane flexible hose, smooth interior and exterior, low water volume (interior Ø 6mm).
Counterweight specific to flexible hose.
F⅜" PEX flexibles with filters and non-return valves.
Reinforced fixing via 2 stainless steel rods.
390,00 €
Ref: 70838 - Ergonomic rinsing head – adjustable 2 jets – G 1/2 ’
> THE PRODUCT BENEFITS > Handle:
Shot blasted: non-slippery with wet gloves
Ergonomic shape and length of the handle: for better grip
Wetting jet: to rinse the dishes
Concentrated spray: to stain dishes
Black and chrome bi-color design: limits the risk of visible stains
Ergonomic hand shower with continuous flow function, and gripping surface limiting the risk of burns. End piece to absorb shocks.
Blocking hook to avoid MSDs (musculoskeletal disorders)
> TECHNICAL SPECIFICATIONS
> Recommended working pressure:
1 to 5 bars
> Flow rate:
12L / min at 3 bar
> Hydraulic supply:
G 1/2 '' (15x 21)
> Material and color of finish:
Chromed brass body
Chromed zamak handle
Injected metal hook
Handle and jet outlet in technical polymer resistant to impact, temperature and compatible with drinking water
> Thermal resistance:
Withstands a temperature of 75 ° C for 30 minutes (in the context of thermal shock).
> Delivered with:
NF check valve
> Standards and approvals:
Chromed brass body compliant with standards NF EN1982 / NF EN 12164 / NF EN 12165 Nickel-Chrome surface treatment according to NF EN12540
Resistance to neutral salt spray (NSS): 200 h according to NF ISO 9227
119,00 €
