Delabie köögisegisti Professionaalne köök G6433

Tootekood: DE-G6433
Kaubamärk:
Ühik: tk
Tarneaeg: 14-21 päeva
Hind:
667,00 €
Kogus: - +
   - või -

Wall-mounted pre-rinse set with mixer
Ref. G6433

Complete pre-rinse set without bib tap.
Wall-mounted mixer, F3/4" with 150mm centres with:
- Valve heads with control knobs.
- Non-return valves integrated in the mixer.
White, scale-resistant M1/2" hand spray with adjustable jet and 9 lpm flow rate at the outlet.
White, reinforced, food-grade flexible hose L. 0.95m.
3/4" brass column.
Adjustable wall bracket.
Stainless steel spring guide.



TECHNICAL FEATURES

Wall-mounted pre-rinse set with mixer
Ref. G6433

Connector F3/4"
Flow rate 9 lpm
Width to the wall 35-162mm
Finish Chrome-plated brass

Failid

Sarnased tooted

keraamilise kartridšiga

H=450mm



Tootekood: IDR-09426/03 ,   Tarneaeg: 14-21 päeva
346,75 € (5%)
365,00 €

Single hole mixer - 100 lpm
Ref. 5610

Deck-mounted single hole mixer H. 315mm L. 300mm with swivelling, tubular spout Ø 22mm.
Star-shaped, brass flow straightener.
Water-free guided valve heads with reinforced mechanisms.
Shock-resistant, ergonomic ball levers.
Flow rate 100 lpm at 3 bar suitable for plunge sinks.
Full flow rate within the first 180°.
Spout with smooth interior.
Chrome-plated brass body and spout.
Soldered copper pipe water inlets.
Reinforced fixings.

Tootekood: DE-5610 ,   Tarneaeg: 7-14 päeva
537,00 €

Twin hole pillar-mounted mixer - 100 lpm
Ref. 5603

Twin hole mixer, M3/4" with 150mm centres on pillar mounts for plunge sinks.
Swivelling, tubular spout Ø 22mm H. 380mm L. 300mm.
Star-shaped, brass flow straightener.
Water-free, guided valve heads with reinforced mechanisms.
Shock-resistant ergonomic ball levers.
Flow rate 100 lpm at 3 bar suitable for plunge sinks.
Full flow rate within the first 90°.
Spout with smooth interior.
One-piece body and spout in chrome-plated brass.
Reinforced fixings and recessed inlets.

Tootekood: DE-5603 ,   Tarneaeg: 7-14 päeva
885,00 €

Pre-rinse set with mixer
Ref. 5626

Complete pre-rinse set without bib tap.
Single hole deck-mounted mixer with slimline control lever.
Supplied with F3/8" flexible hoses and non-return valves.
Black, scale-resistant M1/2" hand spray with adjustable jet and 9 lpm flow rate at the outlet.
Reinforced, food-grade black flexible hose L. 0.95m.
3/4" brass column.
Adjustable wall bracket.
Stainless steel spring guide.

TECHNICAL FEATURES

Pre-rinse set with mixer
Ref. 5626

Connector F3/8"
Height 1105-1225mm
Drop height 340 - 580mm
Flow rate 9 lpm
Width to the wall 35-162mm
Finish Chrome-plated brass
Tootekood: DE-5626 ,   Tarneaeg: 14-21 päeva
810,00 €

Ref: 70814 - Wall-mounted column with 2 holes– rinsing head



> THE PRODUCT BENEFITS

Resistant to intensive use
Spring flexibility
Ergonomic hand shower with continuous flow function, and gripping surface limiting the risk of burns. Tip to absorb shocks. Locking hook to avoid MSDs (musculoskeletal disorders)
Reinforced body / column interface
Intuitive and ergonomic knobs: easy grip
Product design
Wall version: facilitates cleaning and promotes optimal hygiene
Adjustable wall support
PU sheath shower hose to avoid bacterial niches and facilitate cleaning
Easy maintenance: presence of a slot under the red / blue patch allowing the passage of a screwdriver
Ease of maintenance: availability of all spare parts

> TECHNICAL SPECIFICATIONS > Model:

1/4 turn ceramic head mixer
Black M 1/2'' hand shower with grip surface limiting the risk of burns
Shower flow regulated at 12L / min. User adjustable jet: concentrated or wetting. Anti-scale shower head. Locking hook for continuous flow. Integrated non-return valve. Guide spring for stainless steel hose
Adjustable wall support, can be cut from 60 to 200 mm (from column to wall)
Adjustable hand shower holder: left or right

> Recommended working pressure:

1 to 5 bars

> Shower flow:

12L /min at 3 bar

> Hydraulic supply:

G 1/2 '' (15x 21)

> Material and color of finish:

Body and column in chromed brass Injected metal hook
Material compliant with the "UBA" list

> Thermal resistance :

Withstands a temperature of 75 ° C for 30 minutes (as part of thermal shock).

> Delivered with :

Eccentric rosettes
1 filter
1 stainless steel braided hose (hand shower) surrounded by a PU sheath, resistant to temperatures up to 90 ° C. Continuous operating temperature at 70 ° C maximum

> Standards and approvals:

Chromed brass body compliant with standards NF EN1982 / NF EN 12164 / NF EN 12165 Nickel-Chrome surface treatment according to NF EN12540
Resistance to neutral salt spray (NSS): 200 h according to NF ISO 9227

Tootekood: P70814 ,   Tarneaeg: 14-21 päeva
617,00 €
