Self-supporting frame system W. 350mm for wall-hung electronic WC:
Black powder-coated steel frame.
Fixes to load-bearing floors.
Frame height can be adjusted from 0 - 200mm (with 1m mark).
Ø 32mm flush tube with Ø 55mm connection washer.
ABS soil pipe with HDPE sleeve connectors, Ø 110mm outlet with waterproof seal, with 2 setting positions.
Delivered pre-mounted.
Complies with French standard NF D12-208.
Compatible with solid walls from 26 - 130mm.

Fitted with TEMPOMATIC F1" electronic direct flush valve:
Stainless steel wall plate 320 x 220mm.
Shock-resistant infrared presence detection sensor.
Voluntary activation flush when user's hand approaches the sensor or automatically when the user leaves.
Time flow ~7 seconds can be adjusted 3 - 12 seconds.
230/12V transformer.
Integrated stopcock and flow rate adjuster.
Detection distance can be adjusted by the installer.

Combination unit: washbasin and floor-standing WC pan on left sidewith recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030007]

TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 160700
